LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 6
10.Remove the 4 lock screws . and detach the CTL SHIELD with RADIATOR.
Wire "LB" to Hole
㪮㫀㫉㪼㩷㪣㪙
9
CTL-SHIELD with RADIATOR
9
