Sharp LC-42XL2S - Page 60

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 43
9. Remove all the connectors from PWBs.
Wire "LC", "LA2", "LB" to WH
Wire "LC" to WH
Wire "LC", "LA1" to WH
FFC "HM" to WH
Wire "KM", "VD", "US" to WH
Wire "KM" to Hook
Wire "KM" to WH
Wire "RA", "KM", "VD", "US" to
Wire "SP" to WH
Wire "LA1"
Wire "LA2"
Wire "LB"
FFC "HM"
Wire "US"
Wire "VD"
Wire "KM"
Wire "FR"
Wire "LW"
