Sharp LC-42XL2S User Manual

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
3 – 5
Page Line Item Description Remarks (adjustment detail, etc.)
14/33 [MGXX2]
1 MG4R 474 W/B adjustment, gradation 4R adjustment value
2 MG4G 485 W/B adjustment, gradation 4G adjustment value
3 MG4B 384 W/B adjustment, gradation 4B adjustment value
4 MG5R 791 W/B adjustment, gradation 5R adjustment value
5 MG5G 815 W/B adjustment, gradation 5G adjustment value
6 MG5B 673 W/B adjustment, gradation 5B adjustment value
7 MG6R 905 W/B adjustment, gradation 6R adjustment value
8 MG6G 948 W/B adjustment, gradation 6G adjustment value
9 MG6B 800 W/B adjustment, gradation 6B adjustment value
15/33 [ACTIVEBL1]
1 ABL TEST MODE Enter
2 PRINT DEBUG OFF
16/33 [SOUND1]
1 AUDIO_PARAMETER_SWITCH ROM
2AU_FLAT
3 INPUT_MIXER_GAIN
4 OUTPUT_MIXER_GAIN
5 PEQ1_F0
6 PEQ1_Q
7 PEQ1_GAIN
8 PEQ2_F0
9 PEQ2_Q
10 PEQ2_GAIN
11 PEQ3_F0
12 PEQ3_Q
13 PEQ3_GAIN
17/33 [SOUND 2]
1 PEQ4_F0
2 PEQ4_Q
3 PEQ4_GAIN
4 PEQ5_F0
5 PEQ5_Q
6 PEQ5_GAIN
7 GAIN_ADJUSTER1
8 GAIN_ADJUSTER2
9 GAIN_ADJUSTER3
10 GAIN_ADJUSTER4
11 GAIN_ADJUSTER5
12 GAIN_ADJUSTER6_SP
13 GAIN_ADJUSTER6_HP
18/33 [SOUND 3]
1 LOUT1_VOLUME_CONTROL
2 ROUT1_VOLUME_CONTROL
19/33 [M PWM]
1PWM
2PWM FREQ
3 PWM DUTY
4OSC FREQ
5 OSC DUTY
20/33 [M OPC1]
1 OPC LDUTY0
2 OPC LDUTY1
3 OPC LDUTY2
4 OPC LDUTY3
5 OPC LDUTY4
6 OPC LDUTY5
7 OPC LDUTY6
8 OPC LDUTY7
9 OPC LDUTY8
10 OPC LDUTY9
11 OPC LDUTY10
12 OPC LDUTY11
