LC-46D62U/LC-52D62U
4 – 1
LC-46D62U
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS (LC-46D62U)
1. Detach the SD Card Cover .
2. Remove the 4 lock screws and detach the Stand.
3. Remove the 5 lock screws .
4. Remove the 13 lock screws and detach the Rear Cabinet.
1
2
3
4
3
2
2
3
1
4
SD Card Cover
Rear Cabinet
Stand
