LC-52SB55U
4 – 3
9. Remove the 2 lock screws, 2 lock screws and detach the Side AV Cover.
10.Remove the 4 lock shafts, 3 lock screws, 11 lock screws and detach the Main Shield.
Side AV Cover
Main Shield
9
10
10
10
9
