CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: LC-52SB55U
LCD panel
52" screen size class Advanced Super View & BLACK TFT LCD
(Diagonal Measurement : 52
1
/
32
)
Resolution 2,073,600 pixels (1,920 1,080)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 10W 2
Terminals
Rear
INPUT1 AVin,COMPONENTin
INPUT 2 COMPONENT in, S-VIDEO in
INPUT 4 15-pin mini D-sub female connector, Audio in (Ø 3.5 mm jack)
INPUT 6 HDMI in with HDCP, Audio in (Ø 3.5 mm jack)
INPUT 7 HDMI in with HDCP
INPUT 8 HDMI in with HDCP
ANT/CABLE 75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO Audio in (Ø 3.5 mm jack)
DIGITAL AUDIO OUTPUT
Optical Digital audio output 1 (PCM/Dolby Digital)
OUTPUT Audio out
Side
INPUT 3 AV in
INPUT 5 HDMI in with HDCP
SERVICE Software update
OSD language English/French/Spanish
Power Requirement
AC 120 V, 60 Hz (FOR NORTH AMERICA)
AC 110-240 V, 50/60 Hz (FOR OTHERS)
Power Consumption 285 W (0.4 W Standby with AC 120 V)
Weight
TV + stand 62.8 lbs./28.5 kg
TV only 55.1 lbs./25.0 kg
Dimension
*2
(W H D)
TV + stand 49
19
/
64
33
25
/
32
13
1
/
2
inch
TV only 49
19
/
64
31
11
/
32
3
43
/
64
inch
Operating temperature 32°F to 104°F (0°C to 40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the Spanish operation manual.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units.
There may be some deviations from these values in individual units.
"
To Next Page
