LC-52SB55U
4 – 5
12.Remove the 7 lock screws and detach the MAIN Unit, Heat Sink Ass'y.
13.Remove the 5 lock screws and detach the POWER Unit Ass'y.
14.Remove the 6 lock screws and detach the POWER Unit from the Power Fix Angle.
MAIN Unit
Power Fix Angle
POWER Unit
Heat Sink Ass'y
12
12
13
14
