LC-52SB55U
6 – 10
No audio (2)
[PC analog audio input] INPUT-4 No audio. [HDMI analog audio input] INPUT-6 No audio.
Is INPUT-4 selected on the input select menu screen? Is INPUT-6 selected on the input select menu screen?
YES
NO
YES
NO
Is the audio output selected for “VARIABLE” on the
menu screen?
Is the audio output selected for “VARIABLE” on the
menu screen?
Set the audio output to “FIXED”. Set the audio output to “FIXED”.
Is the “PC Audio Select” selected for “Input6(HDMI)”
on the menu screen?
Is the “PC Audio Select” selected for “Input4(PC)” on
the menu screen?
Set the HDMI audio output to “Input4(PC)”. Set the HDMI audio output to “Input6(HDMI)”.
Is the HDMI audio output selected for “Digital” on the
menu screen?
Set the HDMI audio output to “Analog”.
Does the audio signal come from pins(2)(L) and (3)(R) of input terminal(J1801) to pins(46)(L) and (47)(R) of IC1403(CODEC)?
YES
NO
Check the line between J1801 and IC1403, and their
peripheral circuits.
Does the I2S signal come from pins(4)(COD_LRCK), (5)(COD_BCK) and
(6)(COD_SDOUT) of IC1403 to pins(AK24), (AH24) and (AJ24) of
IC8001(CPU)?
NO
Check the line between IC1403 and IC8001.
YES
Does the audio signal come from pins(AP28/AN28)(SPOUT_LN/P), and
(AN29/AP29) to pins(6/5)(INLM/INLP), and (8/9)(INRM/INRP) of
IC2701(AMP)?
NO
Check the line between IC8001 and IC2701, and their
peripheral circuits. (Q1306 thru Q1308, AMP_MUTE
line, etc.)
YES
Is the audio output from IC2701 as specified? NO Check IC2701 and its peripheral circuits.
YES
Check the connector(P2701), speakers and their peripheral circuits.
To Next Page
