LC-60E77UN/LC-65E77UM/LC-C6077UN/LC-C6577UM
6 – 10
No audio (2)
[PC analog audio input] INPUT-4 No audio. [HDMI analog audio input] INPUT-6 No audio.
Is INPUT-4 selected on the input select menu screen? Is INPUT-6 selected on the input select menu screen?
YES
NO
YES
NO
Refer to “: No external input video [INPUT-4]”. Refer to “: No external input video [INPUT-6]”.
Is the audio output selected for “VARIABLE” on the menu screen? Is the audio output selected for “VARIABLE” on the menu screen?
YES
NO
YES
NO
Set the audio output to “FIXED”. Set the audio output to “FIXED”.
Is the “PC Audio Select” selected for “Input4 (PC)” on the menu
screen?
Is the “PC Audio Select” selected for “Input6 (HDMI)” on the menu
screen?
YES
NO
YES
NO
Set the HDMI audio output to “Input4 (PC)”. Set the HDMI audio output to “Input6 (HDMI)”.
Is the HDMI audio output selected for “Digital” on the menu screen?
YES
NO
Set the HDMI audio output to “Analog”.
Does the audio signal come from pins (2) (L) and (3) (R) of input terminal (J1801) to pins (V28)
(L) and (V27) (R) of IC8001 (CPU)?
YES NO
Does the audio signal come from pins (N29/N30) (PGA0OUT_L/R)
of IC8001 (CPU) to pins (4/7) (INLP/INRP) of IC2701 (AMP)?
Check the line between J1801 and IC8001.
YES
NO
Check the line between IC8001 and IC2701,
and their peripheral circuits (Q1306,
AMP_MUTE line, etc.).
Is the audio output from IC2701 as specified? NO Check IC2701 and its peripheral circuits.
YES
Check the connector (P2701), speakers and their peripheral cir-
cuits.
To Next Page
