LC-60E77UN/LC-65E77UM/LC-C6077UN/LC-C6577UM
10 – 18
1
23
1097654
8
J
A
B
C
D
E
F
G
H
I
1311 191816151412 17
KEY Unit
S151
K0003AJ
CH-UP
S152
K0003AJ
CH-DOWN
S153
K0003AJ
INPUT
S154
K0003AJ
VOL-UP
S155
K0003AJ
VOL-DOWN
S157
K0003AJ
POW
D155
EX0646GE
0.0
3.3
D151
EX0646GE
0.0
3.3
D152
EX0646GE
0.0
3.3
R153
8.2K
1/8W
R151
8.2K
1/8W
R152
12K
1/8W
S156
K0003AJ
MENU
R154
12K
1/8W
P151
NA059WJ
TO LCD CONT KM
1
KEY1
2
KEY2
3
STBY_POW
4
NC
5
GND
(QPWBFE266WJ)
DUNTKE266DE
KEY
KEY UNIT
