LC-60E79U
i
LC60E79U
Service Manual
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
In this Service Manual, the modifications from Model LC-60E77UN (No. S99C6LC60E77U) are focused on. For what is left out herein, please refer
back to the Service Manual of the previous model LC-60E77UN (No. S99C6LC60E77U).
DIFFERENCES FROM BASE MODEL
*1 It’s possible to keep compatibility by renewing software.
*2 [RUNTK4499TPYA] and previous two unit are not compatible each other.
*3 It's possible to keep compatibility in same part code.
It's possible to keep compatibility between Taiyo Yoden and Ampower in only 60E79U.
However please use the certainly same maker in a pair.
Taiyo Yuden : RDENC2613TPZA , RDENC2615TPZA
Ampower : RDENC2662TPZZ , RDENC2663TPZZ
Ref No. Description
LC-60E77UN
(No.S99C6LC60E77U)
LC-60E79U
(No.S91T7LC60E79U)
Inter-
change-
ability
Note
PRINTED WIRING BOARD ASSEMBLIES
KEY Unit DUNTKE266FM02 ← — No change
R/C, LED Unit DUNTKF096FM01 ← — No change
MAIN Unit DUNTKF282FM06 DUNTKF282FM19 D Changed *1
POWER Unit RDENCA369WJQZ ← — No change
LCD CONTROL Unit RUNTK4225TPZZ RUNTK4499TPYA D Changed *2
FPGA Unit RUNTK4221TPZA - — Delete
INVERTER-1 Unit RDENC2613TPZZ RDENC2613TPZA D Changed
RDENC2662TPZZ D Changed *3
INVERTER-2 Unit RDENC2615TPZZ RDENC2615TPZA D Changed
RDENC2663TPZZ D Changed *3
LCD PANEL
60” LCD Panel Module Unit R1LK600D3GW10Z R1LK600D3GW1B D Changed
MAIN Unit
IC2002 IC (MONITOR MICON) RH-iXC786WJN4Q RH-iXD196WJN2Q D Changed
CABINET PARTS
Please refer to a Parts list
LCD PANEL MODULE Assembly
Please refer to a Parts list
SUPPLIED ACCESSORIES
Please refer to a Parts list
PACKING PARTS (NOT REPLACEMENT ITEM)
Please refer to a Parts list
SERVICE JIGS (USE FOR SERVICING)
Please refer to a Parts list
Interchangeability
Completely interchangeableA:
=
NEWOLD
Interchangeable from
OLD to NEW
B:
ψ
NEWOLD
Interchangeable from
NEWtoOLD
C:
ψ
NEW OLD
Not interchangeableD:
X
OLDNEW
