Sharp LC-60EQ10U Setup Guide

16
Attaching the Stand/Fixation du socle/Colocación del soporte
ENGLISH
Q
LC-70TQ15U/LC-60TQ15U
• Before attaching (or detaching) the
stand, unplug the AC cord.
• Before performing work spread
cushioning over the base area to lay the
TV on. This will prevent it from being
damaged.
CAUTION
• Be sure to follow the instructions.
Incorrect installation of the stand may
result in the TV falling over.
1
Confirm that there are 9 screws (4
long screws, 4 middle screws and 1
short screw) supplied with the stand
unit.
2
Attach the supporting post for the
stand unit onto the base as shown
below.
• The supporting post attaches to
the base at an offcentered location
on the base. Be sure to attach the
supporting post in the direction
indicated below and attach the
stand to the TV with the wider side
of the base facing forward.
3
Insert the stand into the openings on
the rear of the TV.
• Make sure that the stand is fi rmly
inserted into the TV. Improper
installation may result in tilting of the
TV set.
4
Insert and tighten the 4 screws into
the 4 holes on the rear of the stand
unit.
5
1
Insert the stand cover.
2
Insert the screw to secure the
stand cover.
1
Confirm that there are 9 screws (4
long screws, 4 middle screws and 1
short screw) supplied with the stand
unit.
2
Attach the supporting post for the
stand unit onto the base as shown
below.
• The supporting post attaches to
the base at an offcentered location
on the base. Be sure to attach the
supporting post in the direction
indicated below and attach the
stand to the TV with the wider side
of the base facing forward.
3
Insert the stand into the openings on
the rear of the TV.
• Make sure that the stand is fi rmly
inserted into the TV. Improper
installation may result in tilting of the
TV set.
4
Insert and tighten the 4 screws into
the 4 holes on the rear of the stand
unit.
5
1
Insert the stand cover.
2
Insert the screw to secure the
stand cover.
1
Confirm that there are 9 screws (4
long screws, 4 middle screws and 1
short screw) supplied with the stand
unit.
2
Attach the supporting post for the
stand unit onto the base as shown
below.
• The supporting post attaches to
the base at an offcentered location
on the base. Be sure to attach the
supporting post in the direction
indicated below and attach the
stand to the TV with the wider side
of the base facing forward.
3
Insert the stand into the openings on
the rear of the TV.
• Make sure that the stand is fi rmly
inserted into the TV. Improper
installation may result in tilting of the
TV set.
4
Insert and tighten the 4 screws into
the 4 holes on the rear of the stand
unit.
5
1
Insert the stand cover.
2
Insert the screw to secure the
stand cover.
FRANÇAIS
Q
LC-70TQ15U/LC-60TQ15U
• Avant de poser (ou déposer) le socle,
débranchez le cordon secteur.
• Avant de procéder aux opérations,
étendez un rembourrage sur la surface
de travail pour y placer le téléviseur.
Ceci lui évitera d'être endommagé.
ATTENTION
• Suivez attentivement les instructions.
Un montage incorrect du socle peut
entraîner la chute du téléviseur.
ESPAÑOL
Q
LC-70TQ15U/LC-60TQ15U
• Antes de poner (o quitar) el soporte,
desenchufe el cable de CA.
• Antes de trabajar con el televisor,
extienda un material blando sobre el
área donde va a ponerlo. Esto impedirá
que se estropee el televisor.
PRECAUCIÓN
• Asegúrese de seguir las instrucciones.
La instalación incorrecta del soporte
puede causar la caída del televisor.
2
Q
LC-70TQ15U/LC-60TQ15U
• Long screws
• Vis longues
• Cojín blando
3
1
2
2
1
• Short screws
• Vis courtes
• Tornillos
cortos
• Soft cushion
• Coussin moelleux
• Cojín blando
• In the installation procedure, be
careful not to catch your fingers
between the TV set and the floor.
• Do not remove the stand from the
TV unless using an optional wall
mount bracket to mount it.
• After attaching the stand to the
TV, do not hold the stand when
you put up, set up, move or lay
down the TV.
• Lors de l'installation, faites attention
de ne pas vous coincer les doigts
entre le téléviseur et le sol.
• Ne retirez pas le socle du
téléviseur, sauf si vous utilisez
l'applique pour montage mural en
option pour le monter.
• Après avoir fixé le socle au
téléviseur, ne tenez pas le socle
lorsque vous posez, installez,
déplacez ou fixez le téléviseur.
• Durante el procedimiento de
instalación, asegúrese de que sus
dedos no queden atrapados entre el
televisor y el suelo.
• No quite el soporte del televisor a
menos que utilice una ménsula de
montaje en pared opcional para
montarlo.
• Tras instalar el soporte al
televisor, no sujete el soporte
cuando cuelgue, monte, mueva o
coloque el televisor.

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
