LC-60/70LE660U,C6600U
5 – 4
5. List of adjustment process mode menu
The character string in brackets [ ] will appear as a page title in the adjustment process menu header.
Page Line Item Description Remarks(adjustment detail,etc.)
1 1 Main Version Main Software Version
2 SVN Number Software version number of IC supplier
3 PANEL Version LCD controller software version
4 TEMP SENSOR Panel temperrature
5 NORMAL STANDBY CAUSE
6 ERROR STANDBY CAUSE (*)
2 1 Factory Init Initialization to factory settings
2 Inch Setting
3 Operation Acutime Acumurate Time of TV-SET Operation.
4 RESET Reset the Acumurate Time of TV-SET Operation.
5 1 COMP HD ADJ Auto adjustment of Component A/D for HD signal.
2 Y OFFSET
3 Pb OFFSET
4Pr OFFSET
5 Y GAIN
6Pb GAIN
7Pr GAIN
8 RESET ADJUSTMENT
6 1 RGB ADJ Auto adjustment of RGB A/D for PC signal.
2 G OFFSET
3 B OFFSET
4R OFFSET
5 G GAIN
6 B GAIN
7 R GAIN
8 RESET ADJUSTMENT
7 1 IN POINT LOW_D Standard value Low WB adjustment for DYNAMIC mode
2 IN POINT HIGH_D Standard value High
3 R LEVEL LOW_D WB adjustment Point Low ,R adjustment value
4 G LEVEL LOW_D WB adjustment Point Low ,G adjustment value
5 B LEVEL LOW_D WB adjustment Point Low ,B adjustment value
6 R LEVEL HIGH_D WB adjustment Point High ,R adjustment value
7 G LEVEL HIGH_D WB adjustment Point High ,G adjustment value
8 B LEVEL HIGH_D WB adjustment Point High ,B adjustment value
9 R LEVEL MAX_D WB adjustment Point Max ,R adjustment value
10 G LEVEL MAX_D WB adjustment Point Max ,G adjustment value
11 B LEVEL MAX_D WB adjustment Point Max ,B adjustment value
8
1 IN POINT LOW Standard value Low
In AV MODE : STAN-
DARD,MOVIE,GAME,USER,PC
2 IN POINT HIGH Standard value High
3 R LEVEL LOW WB adjustment Point Low ,R adjustment value
4 G LEVEL LOW WB adjustment Point Low ,G adjustment value
5 B LEVEL LOW WB adjustment Point Low ,B adjustment value
6 R LEVEL HIGH WB adjustment Point High ,R adjustment value
7 G LEVEL HIGH WB adjustment Point High ,G adjustment value
8 B LEVEL HIGH WB adjustment Point High ,B adjustment value
9 R LEVEL MAX WB adjustment Point Max ,R adjustment value
10 G LEVEL MAX WB adjustment Point Max ,G adjustment value
11 B LEVEL MAX WB adjustment Point Max ,B adjustment value
12 ADJ DATA STORE
13 RESET ADJUSTMENT
9 1 EEP CLEAR Clear the EEPROM data
2 STANDBYCAUSE RESET Clear the STANDBY CAUSE history.
3 DESTINATION Indicate the kind of Factory-Initialization command
4 L ERR RESET
Indicate the count of Lamp Error Protection. And
Reset the counter
5 L ERR STOP Lamp Error protection flag (Enable/Disable)
6 TEMP CAUTION Setting for threshold level of High-Temp. caution
7 TEMP SHUTDOWN Setting for threshold level of High-Temp. protection
8 1ST TEMP CONTROL(AD Value)
9 2ND TEMP CONTROL(AD Value)
10 TEST NETWORK UPDATE
