LC-60/70LE660U,C6600U
6 – 14
No audio (3)
No video at UHF/VHF broadcast signal reception No video at digital broadcast signal reception
Is the specified TV signal selected on the input select menu screen?
Are there the IF signal at input pins(24/25)(IF_N/P) of IC3301(CPU)? Are there the IF signal at input pins(24/25)(IF_N/P) of IC3301(CPU)?
YES
NO
Is there IF-AGC signal at input pin(5) of TU1101?
YES
NO
Check the IF signal line between IC3301 and TU1101, and
their peripheral circuits.
Check the IF signal line between IC3301 and TU1101, and
their peripheral circuits.
Check the Tuner I2C lines.
(1)TU1101:pin(10)(SCL), pin(11)(SDA)
(2)IC3301:pin(39), pin(40)
Check the IF-AGC line between pin(38) of IC3301 and
pin(5) of TU1101.
Check the Tuner I2C lines.
(1)TU1101:pin(10)(SCL), pin(11)(SDA)
(2)IC3301:pin(39), pin(40)
Does the analog audio signal come from pins(11/12)(SP_L/SP_R) of IC3301(CPU) to pins(22/32)(SP_L/SP_R) of IC1701(Audio AMP)?
YES
NO
Check the audio line between IC3301 and IC1701, and their paripheral circuits.
•About the L/R Speakers.
Check the connector (P1701) L/R speakers and their peripheral circuits.
YES
Check the RF cable and Antena condition

Sharp LC-60LE660U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	4000000:1
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	AquoMotion 240
3D	No
Teletext function	-
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Package depth	200 mm
Package width	1521 mm
Package height	949 mm
Package weight	31700 g
Sustainability certificates	ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (with stand)	343 mm
Height (with stand)	824 mm
Weight (with stand)	24600 g
Depth (without stand)	86 mm
Width (without stand)	1355 mm
Height (without stand)	781 mm
Weight (without stand)	22800 g
