91
Appendix
Removing the stand
For wall mounting with the bracket remove the stand.
Before setting TV on the wall
• Remove the connected cables (DVD, VCR, etc.) from the
terminals.
• Before performing work, make sure to turn off the TV.
• Before performing work spread cushioning over the base area
to lay the TV on. This will prevent it from being damaged.
NOTE
• To attach the stand, perform the above steps in reverse order.
• As the TV is very heavy, be careful when moving it.
LC-70LE960X/LC-60LE960X
1 Loosen the two screws used to secure the stand
cover.
2 Remove the stand.
1
Unfasten the four screws used to secure the stand in
place.
2
Detach the stand from the TV.
LC-80LE960X
1 Unfasten the screws used to secure the stand in
place.
2 Detach the stand from the TV.
NOTE
• In the installation procedure, be careful not to catch your
fingers between the TV set and the floor.
LC80LE960X_EN_book.indb 91LC80LE960X_EN_book.indb 91 4/4/2014 1:08:32 PM4/4/2014 1:08:32 PM
