[1] CABINET AND MECHANICAL PARTS
1 CCABAB985WJ32 BM N X Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 Not Available - N X Decoration Plate (Center)
1-3 Not Available - X Decoration Plate
1-4 Not Available - X Speaker Net
1-5 PSPAHB406WJZZ AC X Spacer, x2
1-6 PSPAHB407WJZZ AC X Spacer, x2
1-7 TLABZA635WJZZ AC J E-Star Label
1-10 XJPSN30P08XS0 AA J Screw, x3
1-11 Not Available - X Spacer, x2
2 CCABBB237WJK1 BH X Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 HINDPC686WJSA AG X Terminal Label
3 R1LK315T3GW20Z DC J 32" Wide LCD Panel Module Unit
4 GCOVAC612WJ3A AK X Bottom Cover
5 HINDPB715WJSA AF X Terminal Label
6 HINDPC785WJSA AF N X Model Label
7 JBTN-A718WJ3A AF X Operation Button
8 LANGKB343WJZZ AR X Stand Fix Angle
9 LANGKB346WJFW AH X Heat Sink Fix Angle
10 LANGKB364WJFW AC X LCD Fix Angle-A, x2
11 LANGKB365WJFW AC X LCD Fix Angle-B, x2
12 LANGTA476WJZZ AQ X Fix Angle-L, x2
13 LHLDWA133WJKZ AC J Wire Holder
14 LHLDWA143WJKZ AC J Wire Holder, x3
15 LHLDWA151WJKZ AB J Wire Holder
16 LHLDWA175WJUZ AC J Wire Holder, x2
17 LHLDZA928WJ3Z AG X Main PWB Holder, x2
18 LHLDZA933WJKZ AB J Wire Holder
19 LHLDZA934WJKZ AB J Wire Holder
20 NSFTZ0134CEFW AD J Shaft, x2
21 PCLICA004WJKZ AC J Rivet, x4
23 PMLT-A533WJZZ AD X Absorber
24 PRDARA495WJFW AH X
Heat Sink
25 PRDARA510WJFW AR X Heat Sink
26 PSLDMB275WJZZ AQ X Main Shield
27 PSPAKA237WJ00 AA X Spacer, x4
28 PSPAZB086WJKZ AD J Spacer, x2
30 QCNW-G724WJQZ AF X Connecting Cord (KEY-MAIN)
31 QCNW-G725WJQZ AK X Connecting Cord (LED-MAIN)
32 QCNW-H283WJPZ AH X Connecting Cord (SP-MAIN)
33 QCNW-G727WJQZ AK X Connecting Cord (POW-MAIN)
34 QCNW-G728WJQZ AG X Connecting Cord (INV-MAIN)
35 QEARZA123WJZZ AD X Earth Plate
36 QPWBME512WJPZ AN X Connecting Cord (LCD PC-MAIN), x2
37 RCORFA061WJZZ AG J Core, x2
38 RSP-ZA310WJZZ AQ X Speaker (L/R), x2
39 Not Available - - No. Label
40 XBPS830P06000 AA J Screw (for HDMI), x2
41 XEBS930P10000 AA J Screw (for S-Terminal)
42 XEBS940P16000 AB J Screw (for CAB A B), x6
43 XEBSN40P10000 AB J Screw (for CAB A PNL), x4
44 XHPS730P16WS0 AB J Screw (for MAIN PWB2), x4
45 XHPS830P06WS0 AA J Screw (for MAIN PWB), x32
46 XHPS830P10WS0 AB J Screw (for CAB B CHS), x3
47 CDAI-A441WJ07 BH N X Stand Unit
47-1 Not Available - N X Stand Base Ass'y
47-1-1 Not Available - N - Stand Base
47-2 Not Available - X Stand Support Ass'y
47-2-1 Not Available - - Stand Support
47-3 Not Available - X Screw (for Stand), x9
