Sharp LC-C4655U - AQUOS Liquid Crystal Television

LC-C4655U
4 – 3
10.Remove the 2 lock screws and detach the Side AV Cover.
11.Remove the 11 lock screws, 4 lock shafts, 3 lock screws, 2 lock screws and detach the Main Shield.
11
10
Side AV Cover
Main Shield
11
11
11
