Sharp LC55UB30U - J13 Connection [Main BD to WIFI BD]; J11 Connection [Main BD to Speaker]; J2 Connection [Main BD to Power BD]

CONFIDENTIAL – DO NOT COPY
Page 6-2
File No.SG-0000361
J13 CONNECTION [Main BD to WIFI BD]
Pin Description
1 “DVDD33”
2 “USB_DM_P1”
3 “USB_DP_P1”
4 “GND”
5 “WIFI_RESET”
6 “GND”
J11 CONNECTION [Main BD to Speaker]
Pin Description
1 “R+”
2 “R-”
3 “L+”
4 “L-”
J2 CONNECTION [Main BD to Power BD]
Pin Description
1 “PWR_12V”
2 “PWR_12V”
3 “PWR_12V”
4 “GND”
5 “GND”
6 “GND”
