Chapter 14 Complete Parts List
LCD TV 55" LC-55UB30U_AUO_T550QVN03 0_MSD95C0H (FPTW)
Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
1 1 9LE 365502220334 BASE ASS"Y LC-55UB30U_AUO_T550QVN03.0 P Phantom EA 1
2 1 9LE 170105574010 BASE DECO_L(ABS 94-HB/T52013)(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 170105575010 BASE DECO_R(ABS 94-HB/T52013)(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 170105576010 BASE_L(ABS 94-HB/T52013)(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 170105577010 BASE_R(ABS 94-HB/T52013)(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 171212001250 NECK HOLDER L(AL DIE CASTING)(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 171212001260 NECK HOLDER R(AL DIE CASTING)(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 172030049450 MAC. SCREW-MF M4.0*4.5L,BLK-Ni G Assembly Pull EA 8
2 1 9LE 172050030520 MAC.SCREW-MI M3.0*5.0L,Ni G Assembly Pull EA 4
2 1 9LE 172130030650 TAP. SCREW-TF #3.0*6.0L, BLK-Ni G Assembly Pull EA 14
2 11 9LE 172530031050 MAC. SCREW-MF M3.0*10.0L,BLK-NI,NYLOK G Assembly Pull EA 2
2 21 9LE 172530041450 MAC. SCREW-MF M4.0*14.0L,BLK-NI,NYLOK G Assembly Pull EA 4
2 31 9LE 181304022011 BASE BKT_L(SGCC 2.0t)(LC-55UB30U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110001210 FOOT PAD(SILICON/L14.0*W8.0*2.5t)(LIGHT GRAY) G Supplier EA 4
3 1 9LE 171304022010 BASE BKT_L(SGCC 2.0t)(LC-55UB30U) G Supplier EA 1
2 41 9LE 181304023011 BASE BKT_R(SGCC 2.0t)(LC-55UB30U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110001210 FOOT PAD(SILICON/L14.0*W8.0*2.5t)(LIGHT GRAY) G Supplier EA 4
3 1 9LE 171304023010 BASE BKT_R(SGCC 2.0t)(LC-55UB30U) G Supplier EA 1
2 1 9LE 181304032020 NECK BKT(SGCC 2.0t)(LC-65LE654U)ASS'Y G Assembly Pull EA 2
3 1 9LE 171201028650 NECK INNER(SGCC 2.0t)(LC-55LE653U) G Supplier EA 1
3 1 9LE 171304032020 NECK BKT(SGCC 2.0t)(LC-65LE654U) G Supplier EA 1
3 1 9LE 172530030850 MAC. SCREW-MF M3.0*8.0L,BLK-NI,NYLOK G Supplier EA 2
1 1 9LE 365502920315 MRO ASS""Y LC-55UB30U_AUO_T550QVN03.0 P Phantom EA 1
2 1 9LE 192521001731 CORNER BAR(L2400*40*40*4t) G Assembly Pull EA .167
2 1 9LE 192521002090 SLIP SHEET(L1150*W1480*0.9t/OPEN SIDE 1150) G Assembly Pull EA .042
2 1 9LE 192521019440 PAPER SHEET(L1400*W1100*8t) G Assembly Pull EA .084
2 1 9LE 193612000020 FG SHIPPING LBL(#80 art paper)(10cm x 18cm) G Assembly Pull EA .1334
2 1 9LE 193612000030 SHIPPING LBL(#80 art paper)(11cm x 7.5cm) G Assembly Pull EA .0445
2 1 9LE 193613002420 S/N LBL(#80 art paper)(55x15mm) G Assembly Pull EA 1
2 1 9LE 194712008460 CARTON TAPE(L600m*W72mm*0.06t) G Assembly Pull MZ 3.354
2 1 9LE 194725000660 PACKING FILM(L2000m*W500mm*0.0155t) G Assembly Pull MZ 2.323
1 1 9LE 365515220312 PACKING ASS'Y LC-55UB30U_AUO_T550QVN03.0 P Phantom EA 1
2 1 9LE 192510018580 EPS FOAM_TL(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 192510018590 EPS FOAM_TR(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 192510018600 EPS FOAM_BL(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 192510018610 EPS FOAM_BR(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 192510018620 EPS FOAM FRONT(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 192510018820 EPS FOAM_L(LC-55UB30U) G Assembly Pull EA 1
2 1 9LE 192510018830 EPS FOAM_R(LC-55UB30U) G Assembly Pull EA 1
2 11 9LE 192511003140 PE BAG 340*230*0.08T (VOJ370) G Assembly Pull EA 1
2 1 9LE 192511005060 EPE BAG(W1350*L950*0.3t)(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192511005310 PE BAG(W300*L300*0.06t)(LC-50UB30U) G Assembly Pull EA 2
2 1 9LE 192512025040 CARTON(AB/FLUTE) Sharp LC-55UB30U G Assembly Pull EA 1
2 1 9LE 193611017550 B/C LBL(PET 50#)Sharp LC-55UB30U G Assembly Pull EA 1
2 1 9LE 193613002500 S/N LBL(Black) 40*8(PET 50#) G Assembly Pull EA 1
2 1 9LE 193614006010 CTN LBL(art paper 80#)(45x45mm)JVC G Assembly Pull EA 1
2 1 9LE 193614006110 CARTON LBL(art paper 80#)(40*60) Sharp G Assembly Pull EA 1
Child P/N
Confidential- do not copy
Page 14-1
