Sharp LC55UB30U - Display Board I;O Connections; IR Board I;O Connections; WIFI Board I;O Connections

CONFIDENTIAL – DO NOT COPY
Page 6-4
File No.SG-0000361
Display Board I/O Connections
J1 CONNECTION [Display board to Main board]
Pin Description
1 “+5VSB”
2 “GND”
3 “ADIN-1”
4 “ADIN-2”
IR Board I/O Connections
JR1 CONNECTION [IR board to Main board]
Pin Description
1 “IR”
2 “+5V0”
3 “GND”
4 “WHITE”
WIFI Board I/O Connections
CONNECTION [WiFi board to Main board]
Pin Description
1 “DVDD33”
2 “USB_DM_P1”
3 “USB_DP_P1”
4 “GND”
5 “WIFI_RESET”
6 “GND”
