NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
MD-MS200W/MD-MS200/MD-MS200H
C721,722 VCSAFA1AJ335M J AD 3.3 µF,10V
C723,724 VCKYCY1HB102K J AA 1000 pF,50V
C725,726 VCSAFA1AJ335M J AD 3.3 µF,10V
C727 VCKYTV1CF105Z J AB 1 µF,16V
C728 VCKYCY1EF104Z J AA 0.1 µF,25V
C729 RC-KZ1168AFZZ J AC 1 µF,10V,Electrolytic
C730 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C731 VCKYCY1CF224Z J AB 0.22 µF,16V
C733,734 VCKYTV1CB104K J AA 0.1 µF,16V
C751,752 VCKYCY1EB153K J AA 0.015 µF,25V
C753,754 VCKYTV1CF105Z J AB 1 µF,16V
C755 VCKYCY1EB103K J AA 0.01 µF,25V
C756,757 VCKYTV1CF105Z J AB 1 µF,16V
C758 VCSAFA1AJ335M J AD 3.3 µF,10V
C759 VCKRCY1CS563K J AB 0.056 µF,16V
C761,762 VCKYTV0JB105K J AD 1 µF,6.3V
C802 VCKYTV1CF105Z J AB 1 µF,16V
C803 VCKYTV1CB104K J AA 0.1 µF,16V
C804 VCKYTV1CF105Z J AB 1 µF,16V
C805 VCEAPS107AF0J J AC 100 µF,6.3V,Electrolytic
C806 RC-KZ1170AFZZ J AF 3.3 µF,6.3V
C807 VCKYTV1CB104K J AA 0.1 µF,16V
C808 VCKYTV1CB184K J AC 0.18 µF,16V
C809 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C810,811 VCKYTV1CB334K J AC 0.33 µF,16V
C812 VCKYTV1CB184K J AC 0.18 µF,16V
C813 VCKYTV1CF105Z J AB 1 µF,16V
C822 VCCCCY1HH2R0C J AA 2 pF (CH),50V
C823,824 VCCCCY1HH101J J AA 100 pF (CH),50V
C825 VCCCCY1HH5R0C J AA 5 pF (CH),50V
C826 RC-KZ1170AFZZ J AF 3.3 µF,6.3V
C827 VCEAPS227AF0G J AC 220 µF,4V,Electrolytic
C828 VCKYTV0JB105K J AD 1 µF,6.3V
C842 VCCCCY1HH270J J AA 27 pF (CH),50V
C843,844 VCCCCY1HH101J J AA 100 pF (CH),50V
C845 VCCCCY1HH120J J AA 12 pF (CH),50V
C846 VCKYTQ1CB105K J AD 1 µF,16V
C847 RC-KZ1170AFZZ J AF 3.3 µF,6.3V
C848 VCKYTV0JB105K J AD 1 µF,6.3V
C849 VCKYCY1EB103K J AA 0.01 µF,25V
C850 VCKYCY1HB102K J AA 1000 pF,50V
C861 VCKYTV1CF105Z J AB 1 µF,16V
C862 VCKYTV1CB184K J AC 0.18 µF,16V
C863 VCKYTQ1CB105K J AD 1 µF,16V
C865,866 VCKYTQ1CB105K J AD 1 µF,16V
C867 VCEAPS227AF0G J AC 220 µF,4V,Electrolytic
C868 VCKYTV1CF105Z J AB 1 µF,16V
C869 VCEAPS227AF0G J AC 220 µF,4V,Electrolytic
C881 VCKYTV1CB104K J AA 0.1 µF,16V
C882 VCKYTV1CF105Z J AB 1 µF,16V
C902 VCKYCY1EB223K J AB 0.022 µF,25V
C903 VCKYCY1CB473K J AA 0.047 µF,16V
C904 VCKYCY1EB223K J AB 0.022 µF,25V
C905~907 VCKYCY1HB332K J AA 0.0033 µF,50V
C908,909 VCKYTV1CB104K J AA 0.1 µF,16V
C910 VCKYTV1CF105Z J AB 1 µF,16V
C911 VCKYCY1CF104Z J AB 0.1 µF,16V
RESISTORS
VRS-CY1JB000J J AA 0 ohm,Jumper,0.8x1.55mm,
Green
R101 VRS-CY1JB104J J AA 100 kohm,1/16W
R102 VRS-CY1JB123J J AA 12 kohms,1/16W
R104 VRS-CY1JB392J J AA 3.9 kohms,1/16W
R105 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R106 VRS-CY1JB123J J AA 12 kohms,1/16W
R107 VRS-CY1JB124D J AA 120 kohms,1/16W
R109 VRS-CY1JB273D J AA 27 kohms,1/16W
R111 VRS-CY1JB273D J AA 27 kohms,1/16W
R112 VRS-CY1JB124D J AA 120 kohms,1/16W
R113 VRS-CY1JB123J J AA 12 kohms,1/16W
R116 VRS-CY1JB183J J AA 18 kohms,1/16W
R117 VRS-CY1JB224D J AA 220 kohms,1/16W
R119,120 VRS-CY1JB473D J AA 47 kohms,1/16W
R121 VRS-CY1JB224D J AA 220 kohms,1/16W
R122 VRS-CY1JB183J J AA 18 kohms,1/16W
R124,125 VRS-CY1JB184J J AA 180 kohms,1/16W
R126 VRS-CY1JB471J J AA 470 ohms,1/16W
R127 VRS-CY1JB391J J AA 390 ohms,1/16W
R128,129 VRS-CY1JB102J J AA 1 kohm,1/16W
R130 VRS-CY1JB1R0J J AA 1 ohm,1/16W
R131 VRS-CY1JB104J J AA 100 kohm,1/16W
R132 VRS-CY1JB393J J AA 39 kohms,1/16W
R133 VRS-CY1JB154J J AA 150 kohms,1/16W
R134 VRS-CY1JB103J J AA 10 kohm,1/16W
R136 VRS-CY1JB124J J AA 120 kohms,1/16W
R137 VRS-CY1JB223J J AA 22 kohms,1/16W
R138 VRS-CY1JB683J J AA 68 kohms,1/16W
R139,140 VRS-CY1JB473J J AA 47 kohms,1/16W
R141 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R142 VRS-CY1JB153J J AA 15 kohms,1/16W
R143 VRS-CY1JB103J J AA 10 kohm,1/16W
R144 VRS-CY1JB221J J AA 220 ohms,1/16W
R145 VRS-CY1JB335J J AA 3.3 Mohms,1/16W
R151 VRS-CY1JB103J J AA 10 kohm,1/16W
R154 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R160 VRS-CY1JB104J J AA 100 kohm,1/16W
R161 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R171 VRS-CY1JB103J J AA 10 kohm,1/16W
R204 VRS-CY1JB102J J AA 1 kohm,1/16W
R222 VRS-CY1JB105J J AA 1 Mohm,1/16W
R361 VRS-TQ2BB8R2J J AB 8.2 ohms,1/8W
R401 VRS-CY1JB334J J AA 330 kohms,1/16W
R402 VRS-CY1JB102J J AA 1 kohm,1/16W
R403 VRS-CY1JB272J J AA 2.7 kohms,1/16W
R404~406 VRS-CY1JB104J J AA 100 kohm,1/16W
R411 VRS-CY1JB104J J AA 100 kohm,1/16W
R412 VRS-CY1JB103J J AA 10 kohm,1/16W
R413~415 VRS-CY1JB102J J AA 1 kohm,1/16W
R416 VRS-CY1JB123J J AA 12 kohms,1/16W
R417 VRS-CY1JB104J J AA 100 kohm,1/16W
R418 VRS-CY1JB393J J AA 39 kohms,1/16W
R421 VRS-CY1JB103J J AA 10 kohm,1/16W
R422 VRS-CY1JB104J J AA 100 kohm,1/16W
R423 VRS-CY1JB103J J AA 10 kohm,1/16W
R424 VRS-CY1JB104J J AA 100 kohm,1/16W
R425,426 VRS-CY1JB223J J AA 22 kohms,1/16W
R428 VRS-CY1JB153J J AA 15 kohms,1/16W
R429 VRS-CY1JB103J J AA 10 kohm,1/16W
R433,434 VRS-CY1JB104J J AA 100 kohm,1/16W
R435,436 VRS-CY1JB333J J AA 33 kohms,1/16W
R437,438 VRS-CY1JB103J J AA 10 kohm,1/16W
R441~444 VRS-CY1JB102J J AA 1 kohm,1/16W
R445,446 VRS-CY1JB103J J AA 10 kohm,1/16W
R447 VRS-CY1JB223J J AA 22 kohms,1/16W
R448 VRS-CY1JB154J J AA 150 kohms,1/16W [MD-MS200]
R448 VRS-CY1JB393J J AA 39 kohms,1/16W [MD-MS200W]
R448 VRS-CY1JB683J J AA 68 kohms,1/16W [MD-MS200H]
R449 VRS-CY1JB223D J AA 22 kohms,1/16W
R451 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R452 VRS-CY1JB822J J AA 8.2 kohms,1/16W
R453 VRS-CY1JB183J J AA 18 kohms,1/16W
R454 VRS-CY1JB563J J AA 56 kohms,1/16W
R455 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R456 VRS-CY1JB822J J AA 8.2 kohms,1/16W
R457 VRS-CY1JB183J J AA 18 kohms,1/16W
R458 VRS-CY1JB563J J AA 56 kohms,1/16W
R461 VRS-CY1JB363D J AA 36 kohms,1/16W
R462 VRS-CY1JB183D J AA 18 kohms,1/16W
R471 VRS-CY1JB471J J AA 470 ohms,1/16W
R472 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R473 VRS-CY1JB123J J AA 12 kohms,1/16W
R474 VRS-CY1JB473J J AA 47 kohms,1/16W
R500 VRS-CY1JB4R7J J AA 4.7 ohms,1/16W
R501,502 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R601 VRS-CY1JB103J J AA 10 kohm,1/16W
R701,702 VRS-CY1JB101J J AA 100 ohm,1/16W
R703 VRS-CY1JB154J J AA 150 kohms,1/16W
R711,712 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R713,714 VRS-CY1JB103J J AA 10 kohm,1/16W
R715,716 VRS-CY1JB104J J AA 100 kohm,1/16W
R717 VRS-CY1JB102J J AA 1 kohm,1/16W
R719,720 VRS-CY1JB103J J AA 10 kohm,1/16W
R723,724 VRS-CY1JB682J J AA 6.8 kohms,1/16W
R725 VRS-CY1JB101J J AA 100 ohm,1/16W
R726 VRS-CY1JB393J J AA 39 kohms,1/16W
R727 VRS-CY1JB103J J AA 10 kohm,1/16W
R728 VRS-CY1JB102J J AA 1 kohm,1/16W
R751,752 VRS-CY1JB820J J AA 82 ohms,1/16W
R753 VRS-CY1JB154J J AA 150 kohms,1/16W
R754 VRS-CY1JB334J J AA 330 kohms,1/16W
R756,757 VRS-CY1JB273J J AA 27 kohms,1/16W
R761,762 VRS-CY1JB332J J AA 3.3 kohms,1/16W
– 2 –
