PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MS200W/MD-MS200/MD-MS200H
R765,766 VRS-CY1JB180J J AA 18 ohms,1/16W
R801 VRS-CY1JB684D J AA 680 kohms,1/16W
R802 VRS-CY1JB394D J AA 390 kohms,1/16W
R803,804 VRS-CY1JB104J J AA 100 kohm,1/16W
R805 VRS-CY1JB474D J AA 470 kohms,1/16W
R806 VRS-CY1JB684D J AA 680 kohms,1/16W
R810 VRS-CY1JB204D J AA 200 kohms,1/16W
R811 VRS-CY1JB184D J AA 180 kohms,1/16W
R812 VRS-CY1JB103J J AA 10 kohm,1/16W
R821 VRS-CY1JB474J J AA 470 kohms,1/16W
R822 VRS-CY1JB684J J AA 680 kohms,1/16W
R823 VRS-CY1JB335J J AA 3.3 Mohms,1/16W
R824 VRS-CY1JB153J J AA 15 kohms,1/16W
R826 VRS-CY1JB103J J AA 10 kohm,1/16W
R827 VRS-CY1JB474D J AA 470 kohms,1/16W
R828 VRS-CY1JB334D J AA 330 kohms,1/16W
R829 VRS-CY1JB474J J AA 470 kohms,1/16W
R830 VRS-CY1JB220J J AA 22 ohms,1/16W
R841 VRS-CY1JB104J J AA 100 kohm,1/16W
R843 VRS-CY1JB104J J AA 100 kohm,1/16W
R844 VRS-CY1JB153J J AA 15 kohms,1/16W
R846 VRS-CY1JB103J J AA 10 kohm,1/16W
R847 VRS-CY1JB394D J AA 390 kohms,1/16W
R848 VRS-CY1JB274D J AA 270 kohms,1/16W
R849 VRS-CY1JB303J J AA 30 kohms,1/16W
R851 VRS-CY1JB104J J AA 100 kohm,1/16W
R901 VRS-CY1JB563J J AA 56 kohms,1/16W
R902 VRS-CY1JB331J J AA 330 ohms,1/16W
R903,904 VRS-CY1JB1R0J J AA 1 ohm,1/16W
R905 VRS-CY1JB103J J AA 10 kohm,1/16W
R906,907 VRS-CY1JB154J J AA 150 kohms,1/16W
OTHER CIRCUITRY PARTS
CNS101 QCNCWXX26AFZZ J AF Socket,26Pin
CNS201 QCNCW764FAFZZ J AD Socket,6Pin
CNS351 QCNCW764FAFZZ J AD Socket,6Pin
CNS401 QCNCW749PAFZZ J AE Socket,14Pin
CNS402 QCNCW764GAFZZ J AD Socket,7Pin
CNS601 QCNCW764NAFZZ J AE Socket,13Pin
J701 QJAKZ0254AFZZ J AR Jack,OPTICAL/LIVE IN
J702 QJAKM0189AFZZ J AE Jack,MIC IN
J703 QJAKM0200AFZZ J AF Jack,Headphones
J801 QJAKC0123AFZZ J AE Jack,DC IN
M1 RMOTV0480AFZZ J AS Motor Ass’y [Spin]
M902 RMOTV0473AFM1 J AS Motor Ass’y [Fead]
M903 RMOTV0474AFM1 J AS Motor Ass’y [Lift]
SW401 QSW-M0158AFZZ J AD Switch,Push Type
[Disc Cover Open/Close
Detection]
SW402 QSW-S0910AFZZ J AD Switch,Push Type [Hold]
SW901 QSW-M0158AFZZ J AD Switch,Push Type [Lead In]
SW902 QSW-M0160AFZZ J AE Switch,Push Type [Disc Media]
SW903 QSW-M0161AFZZ J AE Switch,Push Type
[Disc Program]
SW904 QSW-M0160AFZZ J AE Switch,Push Type [Disc Media]
MECHANICAL PARTS
1 LANGF1552AFM1 J AG Screw Drive Ass’y
2 LANGF1575AFZZ J AD Spacer,Motor
3 RCTRH8158AF10 J BR Optical Pickup Unit
[MD-MS200W/H]
3 RCTRH8158AF30 J Optical Pickup Unit [MD-MS200]
4 MSPRP0726AFFJ J AA Spring,Shaft
5 LCHSM0926AFM1 J AK Main Chassis Ass’y
6 QPWBH0286AFZZ J AG Head Joint Flexible PWB
7 QPWBH0249AFZZ J AG Mechanism Flexible PWB
8 LANGF1554AFZZ J AC Bracket,Shaft Guide
9 NSFTM0270AFFW J AB Shaft (S)
11 RCILH0107AFZZ J Magnetic Head
13 LHLDX3129AFM2 J AK Cartridge Holder Ass’y
14 MLEVF2591AFM1 J AF Lift Lever Ass’y
15 MSPRD1341AFFJ J AB Spring,Lift Lever
16 NGERH0547AFZZ J AB Rack,Grip
17 MSPRP0800AFFJ J AB Spring,Grip
18 MLEVF2553AFFW J AD Lever,Lift
19 LANGF1555AFZZ J AB Bracket,Lift Lever
20 NSFTM0288AFFW J AC Shaft,Pickup Slide
21 MLEVF2551AFFW J AD Lever,Eject
22 MSPRT1572AFFJ J AB Spring,Eject Lever
23 MSPRT1573AFFJ J AB Spring,Cancel Lever
24 PCUSG0517AFZZ J AA Cushion,Mechanism
30 LANGF1586AFFW J AD Bracket,Head
31 LANGF1556AFFW J AD Bracket,Pickup
32 MSPRD1351AFFJ J AB Spring Head
33 LX-WZ9274AFZZ J AA Washer,ø1.5×0.2mm
34 LX-BZ0900AFZZ J AB Screw,Special
105 LX-BZ0800AFZZ J AA Screw,ø1.4×2.5mm
106 LX-BZ0860AFZZ J AB Screw,ø1.4×5.0mm
107 LX-BZ0825AFZZ J AA Screw,ø1.4×1.5mm
108 LX-SZ0041AFZZ J AB Screw,ø1.7×4.2mm
109 XWSSD14-05000 J AA Washer,ø1.4×0.5mm
110 XAPSN14P02200 J AA Screw,ø1.4×2.2mm
111 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
112 LX-BZ0907AFZZ J AB Screw,ø1.4×3.5mm
114 LX-BZ0830AFZZ J AB Screw,ø1.4×4.5mm
115 LX-BZ0946AFZZ J AB Screw,ø1.4×2.0mm
116 LX-BZ0824AFZZ J AA Screw,ø1.4×3mm
117 LX-BZ0928AFZZ J AB Screw,ø2×4.5mm
118 PCUSG0625AFZZ J Cushion
119 PSHET0353AFZZ J Sheet,Head
M1 RMOTV0480AFZZ J AS Motor Ass’y [Spin]
M902 RMOTV0473AFM1 J AS Motor Ass’y [Fead]
M903 RMOTV0474AFM1 J AS Motor Ass’y [Lift]
SW901 QSW-M0158AFZZ J AD Switch,Push Type [Lead In]
SW902 QSW-M0160AFZZ J AE Switch,Push Type [Disc Media]
SW903 QSW-M0161AFZZ J AE Switch,Push Type
[Disc Program]
SW904 QSW-M0160AFZZ J AE Switch,Push Type [Disc Media]
CABINET PARTS
201 GCABA2795AFSA J AH Center Cabinet
202 RUNTK0419AFZZ J AN Flexible PWB Ass’y
203 LANGF1560AFFW J AC Bracket,Cabinet
204 PCUSG0610AFSA J AC Rubber Preventive Vibration
205 QTANZ9131AFFQ J AC Terminal,Battery,+
206 QTANZ9132AFFQ J AC Terminal,Battery,-
207 LHLDF3233AFM1 J Frame Ass’y
208 GFTAB1309AFSI J AE Cover,Battery
209 LANGK0903AFFW J AG Bracket,PWB
210 LANGZ0302AFM1 J AE Battery Cover Bracket Ass’y
211 GCABB2795AFSA J AG Front Cabinet
212 GFTAC1931AFSA J Cover,MD
213 JKNBZ1908AFSA J AD Knob,Hold
214 GCABC4316AFSA J AS Disc Cover
215 LHLDZ3178AFFW J AD Holder,LCD
216 HDECQ0508AFSA J AK Decoration Plate
217 JKNBZ1986AFM1 J AH Operation Knob Ass’y
219 JKNBZ1911AFSF J AD Knob,Operation
220 RUNTZ0552AFZZ J BA LCD
221 CCABD4323AF01 J Bottom Cabinet Ass’y
[MD-MS200W]
221 CCABD4325AF01 J Bottom Cabinet Ass’y
[MD-MS200]
221 CCABD4326AF01 J Bottom Cabinet Ass’y
[MD-MS200H]
221- 1 ———— — Bottom Cabinet
(Not Replacement Item)
221- 2 PSHET0330AFZZ J AC Sheet,Bottom Cover
224 JKNBK0523AFZZ J Knob,Eject
225 LANGZ0328AFFW J AC Bracket,Eject Knob
226 PSHEZ0746AFZZ J AB Sheet,Eject Knob
227 QPWBH0250AFZZ J AE Flexible PWB,Head Drive
229 PSHEZ0640AFZZ J AC Cover,Terminal
230 LANGZ0304AFFW J AC Bracket,MD Guide
231 PCUSG0586AFZZ J AB Cushion,MD Guide Bracket
233 PCUSG0583AFZZ J AB Cushion,Mechanism
234 PCUSG0585AFZZ J AB Cushion,Mechanism
235 PCUSG0587AFZZ J AB Cushion,Mechanism
236 PCUSG0624AFZZ J Cushion,Mechanism
237 PSHEZ0745AFZZ J AC Sheet,Decoration Plate
239 PSLDC3336AFZZ J AC Shield
240 HDECQ0507AFSA J AF Decoration Plate
241 PCUSG0611AFZZ J AB Cushion,Mechanism
242 PSHET0356AFZZ J LCD Sheet
243 PSHET0355AFZZ J AB Sheet,
244 PCUSG0621AFZZ J AB Cushion,Head
245 PCUSG0622AFZZ J Cushion,Mechanism
246 PCUSG0626AFZZ J AB Cushion,Battery Cover
247 TLABS0465AFZZ J AB Label,Laser Mark
[MD-MS200W/H]
– 3 –
