MD-MT20/20C/20W
– 25 –
SW401 EJECT OFF—ON
SW402 HOLD OFF—ON
SW403 DISC LID OPEN OFF—ON
SW902 DISC PROTECT OFF—ON
NOTES ON SCHEMATIC DIAGRAM
• Resistor:
To differentiate the units of resistors, such symbol as K and
M are used: the symbol K means 1000 ohm and the symbol
M means 1000 kohm and the resistor without any symbol is
ohm-type resistor. Besides, the one with “Fusible” is a fuse
type.
• Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means micro-micro-farad and the unit of the
capacitor without such a symbol is microfarad. As to electro-
lytic capacitor, the expression “capacitance/withstand volt-
age” is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
• The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
• Parts marked with “ ” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
POSITION
REF. NO
DESCRIPTION
Figure 25 TYPES OF TRANSISTOR AND DIODE
1SS372
2SA17457
2SC4213 B
RN1103
TOP
VIEW
TOP VIEW
SB10015 C
TOP VIEW
B
(G)
(3)
E
(S)
1
C
(D)
(2)
1SS361
TOP VIEW
1SS360
TOP VIEW
SBE803
2SA1873 GR
TOP VIEW
To Next Page
