MD-MT20/20C/20W
– 41 –
58 MD1 MD1 Input Operation mode selection input 1
59 P23 INNSW Input Mechanism inner SW position detection input
60 WDTOVF WDTOVF Output Watch dog timer (not used)
61 MD2 MD2 Input Operation mode selection input 2
62 RES _RESET Input Microcomputer hard reset input
63 NMI _NMI Input Nonmaskable interruption (not used)
64 STBY _STBY Input Microcomputer standby input (not used)
65 Vcc VCC — Positive power supply
66 XTAL XTAL — Crystal connection terminal
67 EXTAL EXTAL — Crystal connection terminal
68 Vss VSS — Ground potential
69 PF7 _STOP Input Unit STOP button operation detection input
70 PF6 _PLAY Input Unit PLAY button operation detection input
71 PF5 EMPH0 Output Audio emphasis control output 0
72* PF4 PF4 Output Spare
73 PF3 _DINT Input System LSI interruption
74 PF2 _ARQD Input Disk cap opens and closes detection/it is started and required
75 PF1 _RPLAY Input Remote control PLAY key operation detection
76 IRQ0 _ARQK Input It is started by the button input, requirement
77 AVcc AVCC — A/D and D/A converter positive power supply
78 Vref VREF — A/D and D/A converter reference voltage
79 AN0 PLVBAT Input Battery voltage detection input
80 AN1 PLVDCI Input DC jack voltage detection input
81 P42 TEMP Output Ambient temperature detection input
82 AN3 RKEY Input Remote control key operation detection input
83 AN4 HKEY1 Input Unit key operation detection input 1
84 AN5 HKEY2 Input Unit key operation detection input 2
85 AN6 CHGCNT Output Charging current control output
86 DA1 LDVAR Output P.U. laser power setting output
87 AVss AVSS — A/D and D/A converter ground potential
88 Vss VSS — Ground potential
89 P24 BATOFF Output Battery OFF output
90 TIOCB4 MCMON Output Internal operation status monitor
91 P26 NIHEXT Input Ni-MH battery detection input
92 P27 DCNT1M Output Mechanism driver enable output
93 PG0 SENSE Input System LSI servo sense input
94 PG1 _FOK Input Focus OK signal input
95 PG2 _XRST Output System LSI hard reset output
96 PG3 CKSTP Output Microcomputer standby operation monitor output
97 PG4 _EJSW Input Ejection lever operation detection input
98 Vcc VDD — Positive power supply
99 P10 PCNT2 Output Vcc supply control output of power IC
100 P11 HDON Output Recording head current control output
IC401 RH-iX0298AWZZ: System Microcomputer (IX0298AW) (2/3)
Pin No.
FunctionPort Name Terminal Name
Input/Output
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
