Sharp MD-MT20

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT20/20C/20W
– 1 –
INTEGRATED CIRCUITS
IC101 VHIIR3R55//-1 J AQ RF Signal,Processor,IR3R55
IC200 VHI62FP2002-1 J AE 2.0V Regulator,62FP2002
IC201 VHILR37811/-1 J BB Encode/Decode/Servo Atrac,
LR37811
IC202 RH-IX2567AFZZ J BA 4M bit D-RAM,IX2567AF
IC351 VHI74ACT02T-1 J AE Head Driver,74ACT02T
IC353 VHIFTD2005/-1 J AG Head Driver,FTD2005
IC354 VHICPH5608/-1 J AH Head Driver,CPH5608
IC401 RH-IX0298AWZZ J AX System Microcomputer,
IX0298AW
IC402 VHIS29L294A-1 J AH EEPROM,S29L294A
IC431 VHIS80820LN-1 J AD Reset,S80820LN
IC501 VHIAK4519VF-1 J AQ AD/DA Converter,AK4519VF
IC601 VHIMPC17A39-1 J AQ 4ch PWM Driver,MPC17A39
IC651 VHILB1930M/-1 J AH Head Up/Down Driver,LB1930M
IC701 VHIIR3R54N/-1 J AQ Audio Amp.,IR3R54N
IC702 VHI62GR4522-1 J AG 4.5V Regulator,62GR4522
IC703 VHIIR3R54N/-1 J AQ Audio Amp.,IR3R54N
IC771 VHI62GR2522-1 J AG 2.5V Regulator,62GR2522
IC801 VHIHN1C01FU-1 J AD Over Voltage Reverse
Connection Protection Circuit,
HN1C01FU
IC802 VHIFDC634P/-1 J AG Over Voltage Reverse Connec-
tion Protection Circuit,FDC634P
IC803 VSFDT439N//-1 J AL Charging Circuit,FDT439N
IC805 VHINJM022V/-1 J AG Charging Circuit,NJM022V
IC806 VHINDC631N/-1 J AG Charging Circuit,NDC631N
IC807 VHIRN4904//-1 J AD Charging Circuit,RN4904
IC808 VHIHN1C01FU-1 J AD Charging Circuit,HN1C01FU
IC820 VHI62FP2502-1 J AE 2.5V Regulator,62FP2502
IC821 VHIIR3M09N/-1 J AL DC/DC Converter,IR3M09N
IC822 VHICPH3403/-1 J AE 2.7V Regulator,CPH3403
IC841 VHIXC62HS02-1 J AE 2.35V Regulator,XC62HS02
IC851 VHITC7S14FU-1 J AE 2.35V Regulator,TC7S14FU
IC871 VHIS8324A28-1 J AH 2.8V Up Converter,S8324A28
IC872 VHIS80813LN-1 J AE 2.8V Up Converter,S80813LN
IC901 VHIBA6966FV-1 J AM Spindle Motor Driver,BA6966FV
Q873 VHINDS332P/-1 J AD FETIC,NDS332P
TRANSISTORS
Q101 VS2SA17457/-1 J AB Silicon,PNP,2SA17457
Q251 VSRN1113///-1 J AC Digital,NPN,RN1113
Q252 VS2SC4738GR-1 J AC Silicon,NPN,2SC4738 GR
Q253~255 VSRN1113///-1 J AC Digital,NPN,RN1113
Q461 VS2SC4738GR-1 J AC Silicon,NPN,2SC4738 GR
Q711 VSRN1444A//-1 J AC Digital,NPN,RN1444 A
Q721 VS2SC4213B/-1 J AC Silicon,NPN,2SC4213 B
Q874 VSRN1113///-1 J AC Digital,NPN,RN1113
Q901 VSRN1113///-1 J AC Digital,NPN,RN1113
DIODES
D351 VHDSBE803//-1 J AD Silicon,SBE803
D431 VHD1SS361//-1 J AB Silicon,1SS361
D461 VHDRB731U//-1 J AC Silicon,RB731U
D492 VHE15AZ7R5Y-1 J AC Zener,7.5V,15AZ7.5Y
D494 VHE15AZ7R5Y-1 J AC Zener,7.5V,15AZ7.5Y
D800 VHD1SS360//-1 J AB Silicon,1SS360
D801 VHDSB10015C-1 J AD Silicon,SB10015C
D802 VHE015Z5R1Y-1 J AD Zener,5.1V,015Z5.1Y
D803 VHD1SS382//-1 J AC Silicon,1SS382
D812 VHDSB10015C-1 J AD Silicon,SB10015C
D821 VHDEC30LA02-1 J AF Silicon,EC30LA02
D822 VHD1SS389//-1 J AB Silicon,1SS389
D831 VHD1SS372//-1 J AD Silicon,1SS372
D861 VHDEP10LA03-1 J AD Silicon,EP10LA03
D871 VHDEP10LA03-1 J AD Silicon,EP10LA03
COILS
L100 VPBNN100K0000 J AC 10 µH
L171 RCILC0356AFZZ J AC 10 µH,Choke
L201~206 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L209 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L451 RCILC0352AFZZ J AB Tip Impeder,150mA
L452~454 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L456 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L500 RCILC0344AFZZ J AC 47 µH,Choke
L600 RCILC0331AFZZ J AC 2.2 µH,Choke
L601~604 RCILC0358AFZZ J AC 4.7 µH,Choke
L608~610 RCILC0358AFZZ J AC 4.7 µH,Choke
L702~704 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L711~714 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L719 VPBNNR47K0000 J AC 0.47 µH
L751,752 RCILC0354AFZZ J AC 22 µH,Choke
L771 RCILC0359AFZZ J AC 100 µH,Choke
L821 RCILC0004AWZZ J AF 4.7 µH,Choke
L822 RCILC0005AWZZ J AF 10 µH,Choke
L862 RCILC0359AFZZ J AC 100 µH,Choke
L871 RCILC0344AFZZ J AC 47 µH,Choke
L887,888 RCORF0017AWZZ J AE Tip Impeder
L921 RCILC0353AFZZ J AB Tip Solid Induction,100mA
VIBRATORS
XL201 RCRSC0028AFZZ J AH Crystal,33.868 MHz
XL401 RCRM-0201AFZZ J AD Ceramic,4.19 MHz
CAPACITORS
C100 VCSATA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C102,103 VCKYTV1AB105K J AD 1 µF,10V
C104 VCKYCY1CB273K J AA 0.027 µF,16V
C106 VCKYTV1CB224K J AB 0.22 µF,16V
C107 VCKYCY1EB123K J AA 0.012 µF,25V
C109 VCKYTV1AB105K J AD 1 µF,10V
C110 VCKYTV1CB224K J AB 0.22 µF,16V
C111 VCKYCY1HB332K J AA 0.0033 µF,50V
C112 VCKYCY1CB333K J AA 0.033 µF,16V
C121,122 VCCCCY1HH271J J AA 270 pF (CH),50V
C123,124 VCCSCY1HL391J J AA 390 pF,50V
C130 VCKYCY1CB104K J AB 0.1 µF,16V
C161 VCKYTV1AB105K J AD 1 µF,10V
C165 VCKYCY1CB333K J AA 0.033 µF,16V
C171 VCSATE0JJ107M J AE 100µF,6.3V,Electrolytic,Tantalum
C200,201 VCKYTV1AB105K J AD 1 µF,10V
C202 VCSATE0JJ476M J AD 47 µF,6.3V,Electrolytic,Tantalum
C203 VCKYCY1CB104K J AB 0.1 µF,16V
C204 VCKYTV1CB474K J AC 0.47 µF,16V
C205 VCKYCY1CB104K J AB 0.1 µF,16V
C207 VCKYCY1CB104K J AB 0.1 µF,16V
C209 VCCCCY1HH220J J AA 22 pF (CH),50V
C211,212 VCCCCY1HH5R0C J AA 5 pF (CH),50V
C250 VCKYCY1CB104K J AB 0.1 µF,16V
C253 VCKYTV1CB104K J AA 0.1 µF,16V
C254~256 VCKYCY1CB104K J AB 0.1 µF,16V
C258 VCKYCY1HB472K J AA 0.0047 µF,50V
C351 VCCCCY1HH560J J AA 56 pF (CH),50V
C353 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C354 VCKYCY1CB104K J AB 0.1 µF,16V
C357 VCKYCY1CB104K J AB 0.1 µF,16V
C361 VCKYTV1HB393K J AB 0.039 µF,50V
C401 VCKYCY1CB104K J AB 0.1 µF,16V
C431 VCKYTV1CB474K J AC 0.47 µF,16V
C452 VCKYCY1HB102K J AA 1000 pF,50V
C454 VCKYCY1HB222K J AA 0.0022 µF,50V
C481,482 VCKYTQ1CB105K J AD 1 µF,16V
C491 VCKYTV1CB104K J AA 0.1 µF,16V
C500 VCSATA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C501,502 VCKYCY1HB222K J AA 0.0022 µF,50V
C503,504 VCSATA1AJ335M J AB 3.3 µF,10V,Electrolytic,Tantalum
C505,506 VCKYCY1HB102K J AA 1000 pF,50V
C507 VCSATA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C508 VCKYTV1AB105K J AD 1 µF,10V
C509,510 VCKYTV1CF225Z J AC 2.2 µF,16V
C511 VCKYTV1AB105K J AD 1 µF,10V
C600 VCEAPS226AF0J J AB 22 µF,6.3V,Electrolytic
C601~604 VCKYTV1AB105K J AD 1 µF,10V
C605 VCKYCY1CB104K J AB 0.1 µF,16V
C608 VCKYTQ1CB105K J AD 1 µF,16V
C609,610 VCKYTV1AB105K J AD 1 µF,10V
C622 VCKYCY1CB104K J AB 0.1 µF,16V
C651 VCKYTV1CF105Z J AB 1 µF,16V
C701,702 VCSATA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C703 VCKYCY1EB103K J AA 0.01 µF,25V
C711,712 VCCCCY1HH101J J AA 100 pF (CH),50V
C713,714 VCKYTV1AB105K J AD 1 µF,10V
C715 VCKYCY1CB104K J AB 0.1 µF,16V
C719 VCSATA1AJ106M J AE 10 µF,10V,Electrolytic,Tantalum
C720 VCKYCY1HB102K J AA 1000 pF,50V
C721,722 VCSATA1AJ335M J AB 3.3 µF,10V,Electrolytic,Tantalum
C723,724 VCKYCY1HB102K J AA 1000 pF,50V
C725,726 VCSATA1AJ335M J AB 3.3 µF,10V,Electrolytic,Tantalum
C731 VCKYCY1CF224Z J AB 0.22 µF,16V
