Sharp MD-SR60

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-SR60
R727 VRS-CY1JB822J J AA 8.2 kohms,1/16W
R728 VRS-CY1JB102J J AA 1 kohm,1/16W
R729,730 VRS-CY1JB272J J AA 2.7 kohms,1/16W
R754 VRS-CY1JB154J J AA 150 kohms,1/16W
R757 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R758 VRS-CY1JB101J J AA 100 ohm,1/16W
R761 VRS-CY1JB224J J AA 220 kohms,1/16W
R762 VRS-CY1JB913J J AA 91 kohms,1/16W
R765,766 VRS-CY1JB150J J AB 15 ohms,1/16W
R801 VHHSMDM110V-1 J AK Conductive Restn Switch
R802 VRS-CY1JB561J J AA 560 ohms,1/16W
R803 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R806 VRS-CY1JB563J J AA 56 kohms,1/16W
R807 VRS-CY1JB223J J AA 22 kohms,1/16W
R808 VRS-TV2AB1R0F J AB 1 ohm,1/10W
R809 VRS-TV2AB1R0J J AA 1 ohm,1/10W
R810 VRS-TV2AB1R0F J AB 1 ohm,1/10W
R811 VRS-TV2AB1R0J J AA 1 ohm,1/10W
R812~815 VRS-CY1JB103F J AA 10 kohm,1/16W
R816 VRS-CY1JB152J J AA 1.5 kohms,1/16W
R818 VRS-CY1JB335J J AA 3.3 Mohms,1/16W
R819 VRS-CY1JB223J J AA 22 kohms,1/16W
R823 VRS-CY1JB274J J AA 270 kohms,1/16W
R824 VRS-CY1JB103J J AA 10 kohm,1/16W
R825 VRS-CY1JB304F J AF 300 kohms,1/16W
R826 VRS-CY1JB106J J AA 10 Mohm,1/16W
R827 VRS-CY1JB224F J AA 220 kohms,1/16W
R831,832 VRS-CY1JB184F J AA 180 kohms,1/16W
R833 VRS-CY1JB470J J AA 47 ohms,1/16W
R841 VRS-CY1JB104J J AA 100 kohm,1/16W
R844 VRS-CY1JB470J J AA 47 ohms,1/16W
R850 VRS-CY1JB104J J AA 100 kohm,1/16W
R853 VRS-CY1JB274J J AA 270 kohms,1/16W
R854 VRS-CY1JB103J J AA 10 kohm,1/16W
R855 VRS-CY1JB394F J AA 390 kohms,1/16W
R856 VRS-CY1JB106J J AA 10 Mohm,1/16W
R857 VRS-CY1JB334F J AA 330 kohms,1/16W
R871 VRS-CY1JB103J J AA 10 kohm,1/16W
R901~904 VRS-CY1JB1R0J J AA 1 ohm,1/16W
R906 VRS-CY1JB155J J AA 1.5 Mohms,1/16W
R908 VRS-CY1JB223J J AA 22 kohms,1/16W
R920 VRS-CY1JB104J J AA 100 kohm,1/16W
R921 VRS-CY1JB331J J AA 330 ohms,1/16W
R922 VRS-CY1JB104J J AA 100 kohm,1/16W
OTHER CIRCUITRY PARTS
CN101 QCNCW801XAFZZ J AH Socket,22Pin
CN451 QCNCW804NAFZZ J AE Socket,13Pin
CN482 QCNCW804JAFZZ J AE Socket,9Pin
CN601 QCNCW716RAFZZ J AF Socket,16Pin
! F841 QFS-L401AAFNZ J AE Square Tip Type Fuse,0.4A,
DC60V
J701 VHLGP1FB95R-1 J AP Jack,OPTICAL/LINE IN
J702 QJAKM0014AWZZ J AF Jack,Mic IN
J703 QJAKM0015AWZZ J AL Jack,Remote Control/Head-
phones
J801 QJAKC0007AWZZ J AF Jack,DC IN
M901 RMOTV0028AWZZ J AX Motor Ass’y [Spindle]
M902 RMOTV0511AFZZ J AT Motor Ass’y [Sled]
M903 RMOTV0512AFM1 J AR Motor Ass’y [Lift]
SW401 QSW-M0001AWZZ J AD Switch,Push Type [EJECT]
SW402 QSW-S0948AFZZ J AC Switch,Slide Type [HOLD]
SW403 QSW-M0001AWZZ J AD Switch,Push Type
[LID DETECTION]
SW902(8-3) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
MECHANICAL PARTS
1 NGERH0597AFZZ J AC Wheel,Drive
2 NSFTD0334AFZZ J AD Screw,Drive
3 MARMM0170AFM1 J AK Bracket,Magnetic Field Ass’y
5 LHLDX3141AFM1 J AP Cartridge Holder Ass’y
6 LCHSM0097AWM1 J AQ Main Chassis Ass’y
7 PCUSG0599AFZZ J AB Cushion,Main Chassis
8 QPWBH0004AWM1 J AT Magnetic Flexible PWB Ass’y
8- 1 ———— — Magnetic Flexible PWB
(Not Replacement Item)
8- 2(PH901) VHPGP1S93K/-1 J AF Photo Interrupter
8- 3(SW902) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
9 MLEVF2641AFZZ J AC Lever,Eject
11 MSPRP0923AFZZ J AB Spring,Thrust Plate
12 MSPRP0925AFZZ J Spring,Drive Screw
13 NGERH0603AFZZ J AE Gear,Drive
14 LANGF1610AFZZ J AC Bracket,Cancel
! 15 RCTRH8209AFZZ J Optical Pickup Unit
16 MSPRP0922AFFJ J AD Spring,Drive Grip
17 NSFTM0292AFFW J AC Shaft,Guide
18 MSPRT1625AFFJ J AD Spring,Eject Lever
19 MLEVF2637AFM1 J AH Lift Working Lever Ass’y
20 MLEVF2640AFZZ J AD Lever,Lift
21 RCILH0002AWZZ J AR Magnetic Head
22 PCOVP1339AFZZ J AD Cover,Mechanism
23 QPWBH0338AFZZ J AH Magnetic Head Flexible PWB
24 MLEVF2639AFFW J AD Lever,Lift Joint
25 MLEVF2638AFFW J AD Lever,Block
26 MSPRD1362AFFJ J AD Spring,Lift Lever
501 LX-BZ0800AFZZ J AA Screw,ø1.4×2.5mm
502 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
503 LX-BZ0823AFZZ J AA Screw,ø1.4×1.2mm
504 LX-JZ0148AFZZ J AA Screw,ø1.7×3mm
505 LX-JZ0154AFZZ J AA Screw,ø1.4×2.8mm
506 LX-WZ9290AFZZ J AA Washer,ø0.8×ø2.4×0.2mm
507 XSPSN14P01500 J AA Screw,ø1.7×2.5mm
508 XWSSD14-05000 J AA Washer,ø1.4×0.5mm
509 LX-BZ0974AFZZ J AB Screw,ø1.4×5.5mm
510 LX-WZ9296AFZZ J AA Washer,ø1.5×ø3.5×0.25mm
511 LX-BZ0991AFZZ J AB Screw,ø1.2×1.6mm
512 LX-BZ1001AFZZ J AD Screw,ø1.4×2.3mm
M901 RMOTV0028AWZZ J AX Motor Ass’y [Spindle]
M902 RMOTV0511AFZZ J AT Motor Ass’y [Sled]
M903 RMOTV0512AFM1 J AR Motor Ass’y [Lift]
CABINET PARTS
201 GFTAT3009AWM1 J AV Top Cabinet
202 GCABA1194AWSA J AH Center Cabinet
203 GFTAU3037AWSA J Bottom Cabinet
204 HDECQ0527AWSA J AM Decoration Plate
205 PSHET0021AWZZ J AD Insulation Sheet,Bottom Cabinet
206 PSHEF0019AWZZ J AB Felt
207 GDORB0002AWSA J AF Cover,Battery
208 JKNBZ0666AWSA J AF Knob,Eject
209 JKNBZ0625AWSA J AD Knob,Hold
211 PCUSZ0019AWZZ J AB Cushion,Battery Terminal
212 LANGT0065AWFW J AG Bracket,Display
213 RUNTK0006AWZZ J AQ Key Flexible PWB Ass’y
214 RUNTZ0016AWZZ J BB LCD Ass’y
215 JKNBZ0667AWSA J AK Button,Operation
216 PSHEZ0066AWZZ J AB Sheet,LCD C
218 PCUSZ0016AWZZ J AB Cushion,Display Bracket
219 PSHET0020AWZZ J AB Sheet,Jack
220 PCUSZ0015AWZZ J AB Cushion,Mechanism Front
221 PSHEZ0068AWZZ J AB Spacer,Mechanism
222 PCUSZ0014AWZZ J AB Cushion,Mechanism Right
223 PCUSZ0022AWZZ J AB Cushion,Mechanism
224 PCUSG0051AWZZ J AC Rubber,Preventive Vibration B
225 PCUSG0050AWZZ J AC Rubber,Preventive Vibration A
226 MSPRP0033AWFW J AC Spring B,Cartridge
227 PGIDM0030AW00 J AC Guide,Battery Terminal
228 PCOVW1008AW01 J AC Cover,Battery Terminal,+
229 QTANB9020AWFQ J AD Terminal,Battery +
230 LANGZ0029AWFW J AE Bracket,Side
231 PSHEZ0051AWZZ J AC Sheet,Operation Button A
232 PSHEZ0052AWZZ J AC Sheet,Operation Button B
233 PCUSS0047AWZZ J AB Cushion,LCD B
234 PCUSS0046AWZZ J AB Cushion,LCD A
235 GCOVA1261AWSA J AB Cover,DC Jack
236 MSPRP0032AWFW J AB Spring A,Cartridge
237 LHLDZ3012AWM1 J AF Main Frame Ass’y
240 MSPRP0034AWFW J AB Spring C,Cartridge
241 PCUSZ0021AWZZ J AB Cushion,Display Bracket
601 LX-BZ1008AFFC J AB Screw,ø1.4×2mm
602 LX-BZ0048AWFN J AC Screw,ø1.4×2.5mm
603 LX-CZ0107AFFF J AA Screw,ø1.2×2.5mm
605 LX-BZ0805AFFN J AB Screw,ø1.7×2.5mm
ACCESSORIES
QCNWG0382AFZZ J AK Connecting Cord,RCA Type
QCNWG0422AFZZ J AQ Connecting Cord,Optical Type
! RADPA3048AWZZ J AC Adapter
RPHOH0005AWZZ J AX Headphones
RRMCW0002AWSA J AY Remote Control
– 3 –
