8-5
TROUBLESHOOTING
Contents
Printing on an envelope
The procedure for printing on an envelope is explained below. Only the name and
address side of an envelope can be printed on.
It is recommended that you do a test print to check the print result before using an
envelope.
Type
Size
Fixed Paper Side
Disable Duplex
Paper Property
Bypass
Feeding Approved Job
Disable Staple
Disable Punch
Envelope
COM-10
Tray Settings
Copy
Print
Fax I-Fax
Doc. Filing
5
5
Change
Back
1 Place paper in the bypass tray.
2 Tray Settings.
Type : Envelope
Size : Select the envelope size
Print on the name
and address side
(1)
(2)
(3)
(4)
(5)
3 Select settings in the printer driver.
(1) Click the [Paper] tab.
(2) Select the size of the envelope in
"Paper Size".
(3) Select "Bypass Tray" from "Paper
Source" in "Paper Selection".
(4) Select [Envelope] in "Paper Type".
If needed, select the "Rotate 180 degrees"
checkbox ( ) in "Image Orientation" on the
[Main] tab.
(5) Click the [OK] button.
To Next Page
