MX-3610N EXTERNAL VIEW AND INTERNAL STRUCTURE 3 – 32
B. 36cpm machine
No. Name Function/Operation
1 Switchback gate Switchbacks paper to transport to the ADU section or the right paper exit tray.
2 Paper exit gate Selects the paper path: to transport paper to the ADU section or to the right tray.
3 Document reverse gate Reverses a document when scanning images on the back surface.
2
1
3
