MX-3610N EXTERNAL VIEW AND INTERNAL STRUCTURE 3 – 31
12. Gates
A. 18cpm/20cpm/23cpm/26cpm/31cpm machine
No. Name Function/Operation
1 Switchback gate Switchbacks paper to transport it to the ADU section.
2 Paper exit gate Switchbacks paper to transport it to the right paper exit tray.
3 Document reverse gate Reverses a document when scanning images on the back surface.
