MX-3610N ADJUSTMENTS AND SETTINGS 4 – 2
ADJ 10/
SET1
Color balance and density
adjustment
10D Copy / Image send / FAX
image quality adjustment
(Individual adjustment)
10D
(6)
Document low density image density reproduction
adjustment in the automatic monochrome (Copy/
Scan/FAX) mode (No need to adjust normally)
(Background density adjustment in the scanning
section)
46-32
10D
(7)
Copy/Scan low density image density adjustment
(for each mode) (No need to adjust normally)
46-63
10D
(8)
Color copy, text, line image reproduction
adjustment (edge gamma, density adjustment)
(Text, Map mode) (No need to adjust normally)
46-27
10D
(9)
Monochrome (Copy/Scan/FAX) mode color
document reproduction adjustment
(No need to adjust normally)
46-37
10D
(10)
Color copy mode dark area gradation (black
component quantity) adjustment
(No need to adjust normally)
46-38
10D
(11)
Color (Copy/Scan) mode sharpness adjustment
(No need to adjust normally)
46-60
10D
(12)
Copy high density image density reproduction
setting
(Normally unnecessary to the setting change)
46-23
10D
(13)
Copy color balance adjustment (Single color copy
mode) (No need to adjust normally)
46-25
10D
(14)
RSPF mode (Copy/Scan/FAX) density adjustment
(No need to adjust normally)
46-9
10D
(15)
Automatic color balance adjustment by the user
(Copy color balance automatic adjustment
ENABLE setting and adjustment)
26-53
10D
(16)
Copy gamma, color balance adjustment for each
dither (Automatic adjustment)
46-54
10D
(17)
Dropout color adjustment (Normally not required.)
(26cpm/36cpm/31cpm(A) machine)
46-55
10D
(18)
Watermark adjustment (Normally not required)
(26cpm/36cpm/31cpm(A) machine)
46-66
10E Printer image quality
adjustment (Basic adjustment)
10E
(1)
Printer color balance adjustment
(Automatic adjustment)
67-24
10E
(2)
Printer color balance adjustment
(Manual adjustment)
67-25
10F Printer image quality
adjustment
(Individual adjustment)
10F
(1)
Printer density adjustment (Low density section
density adjustment) (No need to adjust normally)
67-36
10F
(2)
Printer high density image density reproduction
setting (Supporting the high density section tone
gap) (No need to adjust normally)
67-34
10F
(3)
Printer gamma adjustment for each dither
(Automatic adjustment) (No need to adjust
normally) (Except for GDI printers)
67-54
10F
(4)
Au
tomatic color balance adjustment by the user
(Printer color balance automatic adjustment
ENABLE setting and adjustment)
(Normally unnecessary to the setting change)
26-53
ADJ 11 Paper size sensor adjustment 11A Manual paper feed tray paper size (width) sensor adjustment 40-2
11B RSPF paper feed tray document size (width) sensor adjustment 53-6
ADJ 12 Document size detection
adjustment
12A Document size sensor detection point adjustment 41-1
12B Adjust the sensitivity of the original size sensor 41-2
ADJ 13 Touch panel coordinate setting 65-1
ADJ 14 Fusing paper guide position adjustment
ADJ 15 Print image position, image
magnification ratio, void area,
off-center adjustment (Print
engine) (Manual adjustment)
15A Print image magnification ratio adjustment (main scanning direction) (Print engine)
(Manual adjustment)
50-10
15B Print image print area adjustment (Print engine) (Manual adjustment) 50-10/50/1
15C Print image off-center adjustment (Print engine) (Manual adjustment) 50-10
ADJ 16 Scan image magnification ratio
adjustment (Manual adjustment)
16A Scan image magnification ratio adjustment (main scanning direction) (Manual adjustment)
(Document table mode)
48-1
16B Scan image magnification ratio adjustment (sub scanning direction) (Manual adjustment)
(Document table mode)
48-1/48-5
16C Scan image magnification ratio adjustment (main scanning direction) (Manual adjustment)
(RSPF mode)
48-1
16D Scan image magnification ratio adjustment (sub scanning direction) (Manual adjustment)
(RSPF mode)
48-1
ADJ 17 Scan image off-center
adjustment (Manual adjustment)
17A Scan image off-center adjustment (Manual adjustment) (Document table mode) 50-12
17B Scan image off-center adjustment (Manual adjustment) (RSPF mode) 50-12/50-6
ADJ 18 Copy image position, image loss
adjustment (Manual adjustment)
18A Copy image position, image loss, void area adjustment (Manual adjustment)
(Document table mode)
50-1
18B Image scanning position adjustment (Manual adjustment) (RSPF mode) 53-8
18C Copy image position, image loss, void area adjustment (Manual adjustment) (RSPF mode) 50-6
ADJ 19 Finisher and punch unit adjustments (alignment, punch hole position, staple position) 3-10
Job No. Adjustment item list Simulation
