Sharp MX-3640N Technical Guide

MAINTENANCE
SHARP
16
200K MAINTENANCE SCHEDULE:
MX2640N
MX3140N
MX3640N
Description
Every
200K
Every
200K
Every
200K
Process Section:
In addition to Total/Colour/Fuser/Transfer maintenance if indicated:-
Replace PTC unit (MX-230CU).
Sim 24-04 Clear PTC Counter.
Paper Feed & Transport:
Check/Clean Paper Dust Removal Unit.
Check/Clean all Paper Path Sensors (including Duplex unit).
Check/Clean/Replace PF Rollers (check tray counter using Sim 22-09).
Sim 24-04 Clear PS Paper Counter.
General:
Clean all optics, CCD, and white reference plate.
Clean all RSPF sensors.
Fuser Section:
Replace Web Cleaning Kit (MX-360WB).
 Web Roller
 Web Guide Axis x2
 Web Pressure Roller
 Web Pressure Roller Bearing x2
Check & Clean Upper and Lower Thermistors.
Check & Clean Fuser Separator Pawls.
Sim 24-04 Clear Fusing Web Counter.
Every
200K
Every
200K
Every
240K
Transfer Section:
In addition to Total/Colour/Fuser maintenance if indicated:-
Replace Primary (Image) Transfer Belt Kit (MX-230B1).
Replace Primary Transfer Cleaning Blade Kit (MX-230TL).
Clean ID & Registration Sensors.
Sim 24-04 Clear TC1 Belt Counter.
Clear Trans Blade Counter.
Sim 50-22 Drum Position & Registration Adjustment - select ALL.
300/360K MAINTENANCE SCHEDULE:
Every
300K
Every
300K
Every
360K
Process Section:
In addition to Total/Colour/Fuser/Transfer maintenance if indicated:-
Replace Ozone Filter Kit (MX-361FL).
Sim 24-04 Clear Ozone Filter Counter.
