11
* The bypass specifications are for the bypass tray on the machine. The
specifications for the bypass tray for large capacity trays are indicated in a
separate table that follows.
Continuous
copying
speeds*
(when shifter is
not in operation)
(Unit: copies/min.)
MX-7081
Color/B/W
MX-8081
Color/B/W
13" x 19" 33/33 36/36
A3W 33/33 35/35
11" x 17"/A3 34/34 37/37
8-1/2" x 14"/8-1/2" x 13"/8-1/2" x
13-2/5"/8-1/2" x 13-1/2"/B4
39/39 42/42
8-1/2" x 11"/A4/B5 70/75 80/80
8-1/2" x 11"R/7-1/4" x
10-1/2"R/5-1/2" x
8-1/2"R/A4R/B5R/A5R
45/45 48/48
SRA3 35/35 38/38
SRA4 58/58 62/62
A4W 53/53 56/56
* Continuous speed for same original source. Output may
be temporarily interrupted to stabilize image quality.
Copy ratios Same size: 1: 1 ± 0.5 %
Enlarge (Inch size):
121 %, 129 %, 200 %, 400 %
(AB size): 115 %, 122 %, 141 %, 200 %, 400 %
Reduce (Inch size): 25 %, 50 %, 64 %, 77 %
(
AB size):
25 %, 50 %, 70 %, 81 %, 86 %
Zoom range: 25 to 400 % in 1 % increments, total 376
increments. Can calculate zoom rate when mm is specified.
(25 - 200 % using automatic document feeder)
Paper feed /
capacity
1200 plus 800 plus 500 plus 500 ( = 3000) sheets in 4 trays
plus 100-sheet multi-bypass tray
• Using 20 lbs. bond (80 g/m
2
) weight paper
Max. paper
feed / max.
capacity
8500 sheets in 4 trays (1200 + 800 + 500 x 2) plus large
capacity trays (5000) plus 500-sheet multi-bypass tray
• Using 20 lbs. bond (80 g/m
2
) weight paper
Continuous copy
Max. 9999 copies
Memory Standard: 6 GB HDD: 1 TB
1 GB = One billion bytes when referring to hard drive
capacity. Actual format capacity is less.
Ambient
environment
Operating environment 54 °F to 91 °F (10 °C to 35 °C)
(20 % to 85 % RH) 800 - 1,013 hPa
Standard environment 68 °F to 77 °F (20 °C to 25 °C)
(65 ± 5 % RH)
Required power
supply
AC 208-240V/12A, 60Hz
Power consumption
Max. 2.88 kW (including options such as the desk)
Dimensions 33-9/32" (W) x 33-15/64" (D) x 49-3/16" (H)
(845 mm (W) x 844 mm (D) x 1249 mm (H))
(When the operation panel and keyboard are set to the
default position)
Weight Approx. 460.8 lbs. (209kg)
Overall
dimensions
49-1/32" (W) x 33-15/64" (D) (1245 mm (W) x 844 mm (D))
(With multi-bypass tray extended, and the operation panel
and keyboard are set to the default position)
Automatic Document Feeder
Document
feeder types
Duplex Single Pass Feeder (DSPF)
Original paper
sizes
11" x 17" to 5-1/2" x 8-1/2" (A3 to A5), business card
Original paper
types
Paper weight
Thin paper 9 lbs bond to 13 lbs bond (35 g/m
2
to 49 g/m
2
)
Plain paper 13 lbs bond to 40 lbs bond (50 g/m
2
to 157 g/m
2
)
Heavy paper 40 lbs bond to 120 lbs index (158 g/m2 to 220 g/m
2
)
Business card 0.1 to 0.2 mm
Two-sided
Plain paper 13 lbs bond to 40 lbs bond (50 g/m
2
to 157 g/m
2
)
Heavy paper 40 lbs bond to 120 lbs index (158 g/m
2
to 220 g/m
2
)
Business card 0.1 to 0.2 mm
Paper storage
capacity
300 sheets (21 lbs. (80 g/m
2
))
(or maximum stack height of 1-1/2" (38 mm))
Business card: 150 sheets
(or maximum stack height of 1-1/2" (38 mm))
Scan speed Copy mode B/W: 90 one-sided sheets/minute
(600 x 400 dpi)
Color: 60 one-sided sheets/minute
(600 x 600 dpi)
• When scanning one-sided, 8-1/2" x 11" (A4)
vertical documents
Scan mode
(300 dpi)
B/W: 120 sheets/minute (one-sided),
240 pages/minute (two-sided),
Color: 120 sheets/minute (one-sided),
240 pages/minute (two-sided),
• When in standard mode using Sharp
standard paper (8-1/2" x 11" (A4) size with
6% coverage) and the auto color detector is
turned off. The speed varies depending on
the data volume of the original.
Multi Bypass Tray
Name Multi Bypass Tray (MX-MF11)
(For large capacity trays)
Paper sizes
13" x 19" to 5-1/2" x 8-1/2"R (A3 wide to A5R),SRA3, SRA4
Useable paper 13 lbs bond to 80 lbs cover (55 to 220 g/m
2
)
Paper capacity
500 sheets (20 lbs (80 g/m
2
))
(or maximum stack height of 2-11/64" (55 mm))
Required power
supply
Supplied from large capacity trays
Dimensions When paper tray is closed
27-3/4" (W) x 21-57/64" (D) x 8" (H)
(705 mm (W) x 556 mm (D) x 203 mm (H))
When paper tray is pulled out
34-9/16" (W) x 21-57/64" (D) x 8" (H)
(878 mm (W) x 556 mm (D) x 203 mm (H))
Weight Approx. 39.7 lbs (18 kg)
Large Capacity Tray
Name Large Capacity Tray
(MX-LC12)
Large Capacity Tray
(MX-LCX3 N)
Paper sizes 8-1/2" x 11", A4, B5 12" x 18" to 8-1/2" x 11"R
(A3 wide to B5), SRA3,
SRA4
Useable paper 16 lbs bond to 80 lbs cover
(60 to 220 g/m
2
)
16 lbs bond to 80 lbs cover
(60 to 220 g/m
2
)
Paper capacity 3500 sheets
(20 lbs (80 g/m
2
))
3000 sheets
(20 lbs (80 g/m
2
))
Required power
supply
Supplied from the machine Supplied from the machine
Dimensions 14-13/16" (W) x 22-43/64"
(D) x 20-5/8" (H)
(376 mm (W) x 576 mm (D) x
524 mm (H))
26-3/8" (W) x 22-7/16" (D) x
20-43/64" (H)
(670 mm (W) x 570 mm (D) x
525 mm (H))
Weight Approx. 64 lbs (29 kg) Approx. 110 lbs (50 kg)
Large Capacity Trays
Name Large Capacity Trays (MX-LC13 N)
Paper sizes 13" x 19" to 8-1/2" x 11" (A3 wide to B5R) ,SRA3, SRA4
Useable paper 13 lbs bond to 110 lbs cover (55 to 300 g/m
2
)
Paper capacity 5000 sheets (2500 x 2 20 lbs (80 g/m
2
))
Required power
supply
AC 120V/15A ,60Hz
Dimensions 35-1/4" (W) x 30-1/32" (D) x 38-13/16" (H)
(895 mm (W) x 763 mm (D) x 986 mm (H))
Weight Approx. 288 lbs (131 kg)
