12
*
Output capacity may vary depending on environmental conditions at the installation
location, the type of paper used, and the storage condition of the paper.
Finisher / Saddle Stitch Finisher
Name Finisher (MX-FN34)
Saddle Stitch Finisher (MX-FN35)
Paper sizes Depends on feeder specifications
Useable paper Paper weight 13 lbs. to 110 lbs. Cover (55 g/m
2
to 300 g/m
2
)
No. of trays MX-FN34: 2 (Upper tray / Lower tray)
MX-FN35: 2 (Upper tray / Lower tray) + Saddle stitch tray
Tray capacity
(13-20 lbs. bond
(60-80g/m
2
))
Upper tray
Non-stapled 12" × 18", 11" × 17", 8-1/2" × 14", 8-1/2" x 13",
8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" × 11"R,
7-1/4" × 10-1/2"R (A3 wide, A3, B4, A4R, B5R,
SRA3, SRA4, A4 wide,8K, 16KR): 125 sheets
8-1/2" × 11", 5-1/2" × 8-1/2", 5-1/2" ×
8-1/2"R (A4, B5, A5R, 16K): 250 sheets
Lower tray
Non-stapled
12" × 18", 11" × 17", 8-1/2" × 14",
8-1/2" x
13", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" ×
11"R, 7-1/4" × 10-1/2"R,
5-1/2" × 8-1/2",
5-1/2" × 8-1/2"R, 7-1/4" ×10-1/2"R (A3
wide
,
A3, B4, A4R, B5R, A5R, SRA3, SRA4, A4
wide
, 8K)
: 1500 sheets
8-1/2" × 11" (A4
, B5
): 3000 sheets
Staple function
11" × 17", 8-1/2" × 14", 8-1/2" x 13",
8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" ×
11"R (A3, B4, A4R): 100 units or 1500 sheets
8-1/2" × 11" (A4
, B5
, 16K): 200 units or
3000 sheets
Stapleless staple
11" × 17" (A3, 8K): 100 units
8-1/2" × 11" (A4, 16K): 200 units
Saddle stitch tray (MX-FN35)
1 to 5 sheets: 25 units
6 to 10 sheets: 15 units
11 to 20 sheets: 10 units
Max. no. of
stapled sheets
Staple function
Max. no. of 65 sheets (8-1/2" × 11" (A4, B5, 16K))
Max. no. of 2 sheets (110 lbs. Cover (300
g/m
2
)) + 63 sheets (24 lbs. (90 g/m
2
))
Max. no. of 30 sheets (11" × 17", 8-1/2" ×
14", 8-1/2" x 13", 8-1/2" x 13-1/2", 8-1/2" x
13-2/5", 8-1/2" × 11"R (A3, B4, A4R, 8K))
Stapleless staple
Max. no. of 5 sheets (17 lbs. (64 g/m
2
) or less)
(11" × 17", 8-1/2" × 11" (A3, A4, 8K, 16K))
Staple position 1 bottom (slant), 1 top (slant), 2 middle
Manual staple Staple position: 1 top
Max. no. of stapled sheets: 23/64" (9 mm) or less
Saddle Stitch
(MX-FN35)
Staple method
Centered fold with stapling in 2 center places
Saddle stitch fold position
Centered fold
Saddle usable sizes
12" × 18", 11" × 17", 8-1/2 × 14", 8-1/2" × 11"R, 8-1/2" x
13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" × 11"R (A3W,
A3, B4, A4R, 8K, 16KR)
Saddle usable paper weight
13 lbs. to 140 lbs. Cover (55 g/m
2
to 256 g/m
2
)
Paper weighting 28 lbs. to 140 lbs. Cover (106 g/m
2
to 256
g/m
2
) is only able to be used in cover mode and for single
sheet fold.
Max. no. of saddle-stitched sheets
Max. no. of 20 sheets (20 lbs. (80g/m
2
))
19 sheets (20 lbs. (80g/m
2
)) + 1 sheet (110 lbs. Index (209 g/m
2
))
Required power
supply
Supplied from main machine
Weight MX-FN34: Approx. 72.8 lbs. (33 kg)
MX-FN35: Approx. 125.7 lbs. (57 kg)
Dimensions When output paper tray is stored
20-63/64" (W) x 25-23/32" (D) x 43-7/16" (H)
(533 mm (W) x 653 mm (D) x 1103 mm (H))
When output paper tray is extended
25" (W) x 25-23/32" (D) x 45-61/64" (H)
(635 mm (W) x 653 mm (D) x 1167 mm (H))
Finisher (Large stacker) / Saddle
Stitch Finisher (Large stacker)
Name Finisher (MX-FN21)
Saddle Stitch Finisher (MX-FN22)
Paper sizes Depends on feeder specifications
Useable paper Paper weight 13 lbs. to 110 lbs. Cover (55 g/m
2
to 300 g/m
2
)
No. of trays MX-FN21: 3 (Upper tray / Middle tray / Lower tray)
MX-FN22: 4 (Upper tray / Middle tray / Lower tray) + Saddle
stitch tray
Tray capacity
(20 lbs. bond
(80g/m
2
))*
Upper tray
Non-stapled 13" x 19", 12" x 18", 9" x 12", 11" x 17",
8-1/2" x 14", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R (SRA3, SRA4, A3 wide,
A4 wide, A3, B4, A4R, B5R): 750 sheets
8-1/2" x 11", 5-1/2" x 8-1/2"R (A4, B5,
A5R): 1500 sheets
Staple function 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R (A3
wide, A3, B4, A4R, B5R): 50 units or 750
sheets
8-1/2" x 11" (A4, B5): 100 units or 1500
sheets
Middle tray
Non-stapled 13" x 19", 12" x 18", 9" x 12", 11" x 17",
8-1/2" x 14", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R (SRA3, SRA4, A3 wide,
A4 wide, A3, B4, A4R, B5R): 125 sheets
8-1/2" x 11", 5-1/2" x 8-1/2"R (A4, B5,
A5R): 250 sheets
(Offset output is not available)
Lower tray
Non-stapled 13" x 19", 12" x 18", 9" x 12", 11" x 17",
8-1/2" x 14",8-1/2" x 11"R, 7-1/4" x
10-1/2"R (SRA3, SRA4, A3 wide, A4
wide, A3, B4, A4R, B5R,): 750 sheets
8-1/2" x 11", 5-1/2" x 8-1/2"R (A4, B5,
A5R): 2500 sheets (Offset output: 1500
sheets)
(For A3 wide, B5R, A5R, offset output is
not available.)
Staple function 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R (A3
wide, B4, A3, A4R, B5R): 50 units or 750
sheets
8-1/2" x 11" (A4, B5): 100 units or 1500
sheets
Saddle stitch tray (MX-FN22)
Non-stapled 16 lbs bond to 28 lbs bond (60 to
105 g/m
2
): 5 sheets
Staple function 16 lbs bond to 21 lbs bond (60 to
81.4 g/m
2
): 5 units (16 to 20 sheets), 10
units (11 to 15 sheets), 15 units (6 to 10
sheets), 25 units (1 to 5 sheets)
21 lbs bond over to 28 lbs bond
(81.4 g/m
2
over to 105 g/m
2
): 15 units (6
to 10 sheets), 25 units (1 to 5 sheets)
Staple function 16 lbs bond to 21 lbs bond (60 to
in cover mode 81.4 g/m
2
): 5 units (16 to 20 sheets),
10 units (1 to 15 sheets)
21 lbs bond over to 28 lbs bond
(81.4 g/m
2
over to 105 g/m
2
): 10 units
(1 to 10 sheets)
• Offset output is not available for 13" x 19", 12" x 18" /
7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R (A3 wide, B5R, A5R).
Max. no. of
stapled sheets
(20 lbs. bond
(80g/m
2
))
Max. no. of 100 sheets (8-1/2" x 11" (A4, B5))
Max. no. of 50 sheets (11" x 17", 8-1/2" x 14", 8-1/2" x 11"R
(A3, B4, A4R))
Staple position Front: 1 position (slant), Back: 1 position (slant),
Center: 2 positions
