20
BEFORE USING THE MACHINE
LOAD PAPER INTO THE TRAY 3/4
1
Pull out the paper tray.
Gently pull the tray out until it stops.
To load paper, go to step 3. To load a different size of paper,
go to the next step.
Keep holding the handle until the lock is released.
2
Adjust guide plates A and B by
squeezing their lock levers and sliding
them to match the longitudinal and
transversal dimensions of the paper to
be loaded.
The guide plates A and B are slidable. Slide each guide
plate while squeezing its lock lever to adjust to the paper
size.
A non-standard size of paper can only be loaded in tray 4. A non-standard size of paper cannot be loaded in tray 3.
3
Fan the paper.
Fan the paper well before loading it. If the paper is not
fanned, multiple sheets may feed at once and cause a
misfeed.
4
Insert the paper into the tray.
Load the paper with the print side facing up. The stack must
not be higher than the indicator line (maximum of 500
sheets).
To Next Page
