Component locations
432
Connector
Connects to
Pin no.
Signal
JLVPS1
LVPS
1
PS_ZERO_X
2
PS_HEAT2_ON
3
PS_HEAT1_ON
4
GND
5
V15_RELAY_DRIVE
6
GND
7
PS_25V_ON
8
GND
9
PS_PM_TX
10
PS_PM_RX
11
+6.5V
12
GND
13
+6.5V
14
GND
15
+25V_RAW
16
GND
17
+25V_RAW
18
GND
19
+25V_RAW
20
GND
21
+25V_RAW
22
GND
23
+25V_RAW
24
GND
25
+25V_RAW
26
GND
JC AR T P 1
CM cartridge motor
1
V45_CM_CART_W
2
V45_CM_CART_V
3
V45_CM_CART_U
4
V45_Y_CART_W
5
V45_Y_CART_V
6
V45_Y_CART_U
