Component locations
439
Connector
Connects to
Pin no.
Signal
JLCD1
LCD display
1
LED_DRV_YLW2
2
+5VL
3
GSPI_TXD
4
MIR_SPI_CS
5
PWR_BUTTON_R2
6
NC_SPICS_EXPN1
7
NC_SPICS_EXPN2
8
GSPI_RXD
9
V15_UI
10
GSPI_CLK_UIC
11
GND
12
I2CDATA_PANEL
13
I2CCLK_PANEL
14
V15_UI
15
UIPIN24
16
OP_IRQ_R2-
17
GND
18
LVDS_UI_D3R+
19
LVDS_UI_D3R-
20
V15_UI
21
LVDS_UI_CLK_L+
22
LVDS_UI_CLK_L-
23
GND
24
LVDS_UI_D2R+
25
LVDS_UI_D2R-
26
V15_UI
27
LVDS_UI_D1R+
28
LVDS_UI_D1R-
29
GND
30
LVDS_UI_D0R+
31
LVDS_UI_D0R-
32
V15_UI
MTG1
GND
MTG2
GND
