SIDE AND BACK
This section describes the names and functions of the respective parts on the side and
back of the machine.
USB port (A type)
This is used to connect a USB device such as a USB memory device to the machine.
Supports USB 2.0 (Hi-Speed).
USB port (B type)
A computer can be connected to this connector to use the machine as a printer.
For the USB cable, use a shielded cable.
Supports USB 2.0 (Hi-Speed).
LAN connector
Connect the LAN cable to this connector when the machine is used on a network.
Use a shielded LAN cable.
Service-only connector
Tap the name to make its details pop up.
This connector is for use only by service technicians.
Connecting a cable to this connector may cause the machine to malfunction.
Important note for service technicians:
The cable connected to the service connector must be less than 118" (3 m) in length.
