FINISHER
Overview
This device outputs sorted paper while staggering each set of paper. As needed, it
staples each set.
To punch holes in printed paper, install an optional hole punch module.
Function names
Supplies
Finisher maintenance
Function names
The following describes the parts that appear when the finisher is open.
Output tray
Stapled and offset output is delivered to this tray.
The tray is slidable. Extend the tray for printing on large-size paper (A3W, A3, A4R, B4, B5R, 8K,
16KR, 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5",
8-1/2" x 11"R and 7-1/4" x 10-1/2"R sizes).
Lever
Use this lever to move the finisher in order to remove a paper misfeed, replace staples, or remove
a staple jam.
Punch waste box (when a punch module is installed)
This stores punch waste discharged from punching.
Front cover
Open this cover to remove a paper misfeed, replace staples, remove a staple jam, or remove the
punch scrap case.
Staple case
This holds the staple cartridge. Pull the case out to replace the staple cartridge or remove a
staple jam.
Staple case release lever
