Sharp PN-70SC3 User Manual

9
E
Changing the icon size
1. Touch the “Settings” button (
) on the toolbar.
2. Select “Square Menu” in “Menu”.
3. Select “Large” or “Small” in “Icon Size”.
n
Classic menu
The menu can be displayed in classic mode (large or small icon size).
Pan window (Only appears in whiteboard mode.) (Page 43)
Shows the current screen magnication.
Enlarges or reduces the view between 50% and 400% in increments of 25%.
The toolbar is displayed on the left side or the right side of the screen.
The menu can be moved to left/right by touching the icon (
or ).
When set to the unpin setting, the menu automatically disappears when a xed time elapses after the touch pen is moved away
from the menu. (Page 7)
When the toolbar is hidden, the show toolbar icon (
or ) appears. Touch the show toolbar icon to show the toolbar.
TIPS
• The menu icon types that appear by default are the same as in the square menu and oating menu.
• In classic menu, 1 menu is used for the settings, even when using multiple pens. When using multiple pens, the line color and
width are the same for all pens.
Setting to classic menu
1. Touch the “Settings” button (
) on the toolbar.
2. Select “Classic Menu” in “Menu”.
3. Select “Large” or “Small” in “Icon Size”.
To return to the normal menu, select “Square Menu”.

Sharp PN-70SC3 Specifications

General

Panel life	- h
Pixel pitch	- mm
Screen shape	Flat
Response time	6 ms
Backlight type	Edge LED
Display diagonal	70 \
Touch technology	Multi-touch
Display brightness	300 cd/m²
Display technology	LED
Native aspect ratio	16:9
LED backlighting type	Edge-LED
Touchscreen technology	Infrared
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	176.6 cm
Number of simultaneous touchpoints	6
Ethernet LAN	No
HDMI ports quantity	3
VGA (D-Sub) input ports	1
HDMI output ports quantity	0
Bundled software	SHARP PenSoftware
Placement supported	Horizontal
Multi-display supported	-
Product color	Black
Product design	Digital signage flat panel
Bezel width (top)	40.5 mm
Heavy metals free	Hg (mercury)
Bezel width (side)	39 mm
Bezel width (bottom)	77 mm
Panel mounting interface	400 x 400 mm
RMS rated power	20 W
Number of built-in speakers	2
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	235 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	109 mm
Width	1633 mm
Height	994.5 mm
Weight	59000 g
