Controlling the Monitor with a computer (RS-232C)
You can control this monitor from a computer via RS-232C
(COM port) on the computer.
Communication conditions
Set the RS-232C communication settings on the computer to
match the monitor’s communication settings as follows:
• Set "COMMAND (RS-232C)" to ON in "ADMIN" > "CONTROL
FUNCTION" on the Setting menu.
Computer connection
Connect with RS-232 straight cable between the computer’s
COM port (RS-232C connector) and the RS-232C input
terminal on the monitor.
To COM port
Computer
RS-232 straight cable
RS-232C (commercially available)
input terminal
