42
E
Controlling the Monitor with a PC (RS-232C)
Function
Command Direction
Parameter Reply Control/Response contents *
ID SETTING ID NO.SETTING IDST W 0-255 Sets the monitor’s ID number. (“0” means “no ID number”.)
○
R 0-255 Returns the monitor’s ID number.
ID NO. SETTING
(ONCE)
IDSL W 1-255 Sets a monitor ID number.
This ID number is only effective for the command immediately after this command.
0 Clears the ID number if one has been designated.
ID NO. SETTING
(SUBSEQUENT)
IDLK W 1-255 Sets a monitor ID number.
This ID number is effective for the next and all subsequent commands after this
command.
0 Clears the ID number if one has been designated.
ID CHECK IDCK W 0 ID : xxx
IDLK : yyy
Displays monitor’s own ID number and the selected ID number on the screen.
ID DISPLAY IDDP W 0-2 0: OFF, 1: ON, 2: ON (turns OFF after 4 sec.)
(The IP address and MAC address are both displayed.)
-
REMOTE No. RCNO WR 0-9 0-9 Sets the number of the remote control to operate.
○
COPY SETTING
VALUE
SETTING COPY
MODE
CPMD WR 0 0 Copy to all monitors.
1-255 1-255 Copy to the monitor with the set ID Number.
SETTING COPY
TARGET
CPTG WR 0 0 Copies the PICTURE menu settings.
1 1 Copies all the settings.
SUPPLY USB POWER PWSP WR 0-1 0-1 0: POWER ON ONLY, 1: ALWAYS
-
MONITOR menu
Function
Command Direction
Parameter Reply Control/Response contents *
PORTRAIT/LANDSCAPE INSTALL STDR WR 0-1 0-1 0: LANDSCAPE, 1: PORTRAIT
○
HORIZONTAL INSTALLATION MLAY WR 0-2 0-2 0: OFF, 1: UPWARD, 2: DOWNWARD
ROTATE 180° PFIL WR 0, 3 0, 3 0: OFF, 3: ON
“ERR” when PIP MODES is a value other than OFF.
OSD H-POSITION OSDH WR 0-100 0-100 “ERR” when PORTRAIT/LANDSCAPE INSTALL is set to PORTRAIT.
OSD V-POSITION OSDV WR 0-100 0-100
POWER SAVE MODE STBM WR 0-1 0-1 0: OFF, 1: ON
“ERR” when SUPPLY USB POWER is set to ALWAYS.
OFF IF NO
OPERATION
SET ATOF WR 0-1 0-1 0: OFF, 1: ON
TIME AOFT WR 1-12 1-12 1-12 hours
POWER ON DELAY SET PODS WR 0-1 0-1 0: OFF, 1: ON
INTERVAL PWOD WR 1-60 1-60 1-60: seconds
SELF ADJUST SELF ADJUST AADJ WR 0-1 0-1 0: OFF, 1: ON
START TIMING AADD WR 10-200 10-200 10: 1 second through 200: 20 seconds
