9
E
ENGLISH
■ Connection with RS-232 cable
IfyouconnectthemonitorinadaisychainusingRS-232
cable,usingthemonitorbuttonsontheprimary(mainunit),
settingsarecopiedtothesecondary(expansionunit)and
operation from the primary can perform operation for all
monitors.SettingeachIDNo.inthemonitorisrequired.
1. Connect the monitors in order.
Therstmonitorwillbesetasprimary(mainunit)andthe
secondmonitorandbeyondwillbesecondaries(expansion
units).
ConnecttheRS-232Coutputterminaloftherstmonitor
(primary)andtheRS-232Cinputterminalofthesecond
monitor(secondary)togetherusingRS-232cable(straight).
Connectinthesamewaytothethirdandsubsequent
monitors.
Upto25monitorscanbeconnected.(Dependingonthe
lengthofthecableusedandthesurroundingenvironment.)
RS-232 straight cable
(commercially available)
First monitor: primary
Second monitor: secondary
Third monitor: connects to secondary
RS-232C input terminal
RS-232C
input terminal
RS-232C
output terminal
RS-232C
output terminal
2. Set the ID No.
Performoperationwiththerearsidebuttonsontheprimary
monitor.IfyousetAUTOASSIGNIDNo.,locatedinthe
menuofthemonitortoON,theIDNo.willbeautomatically
assignedinorderfromtheprimary.(SeeOperationGuide.)
(Ifyouattachthecontrolkit(optional),youcanperform
operationofthemonitorswiththeremotecontrolunit.)
■ Connection with the control kit (optional)
Ifperformingoperationofthemonitorwiththeremotecontrol
unit,thePN-ZR01controlkit(optional)isrequired.
• Canperformoperationofanarbitrarymonitororall
monitorswiththeremotecontrolunitoftherstmonitor.
• Canperformoperationofupto25monitors.
• ConnectthemonitorstogetherinadaisychainwithRS-232
cable.
Attachtheremotecontrolsensorboxasshowninthefollowing
illustration.
* When attached to the left side, because the top and
bottomfortheremotecontrolsensorboxwillbereversed
(theconnectioncablewillbeontop),therightsideis
recommended.
Caution
• Whenattachingtheremotecontrolsensorbox,turnthe
mainpowerswitchOFF.
• Exceptfortheremotecontrolsensorboxconnectioncable,
donotinsertanyothercableintothecontrolkitterminal.
Also,donotconnectanyconnectioncablesthathavebeen
extendedwithcommerciallyavailablecables.
For the monitor in
horizontal orientation
For the monitor in
vertical orientation
1. Insert the anti-rotation protrusion of the mounting
bracket into the anti-rotation hole of the monitor.
2. Secure the stand angling hole of the monitor with the
mounting screw.
3. Adjust the angle of the remote control sensor box, and
secure it with the xing screw, so that it may accurately
receive signals from the remote control unit.
Anti-rotation protrusion
Angle
adjustment
Anti-rotation hole
Mounting bracket
Mounting screw (short)
Fixing screw
Remote control
sensor box
Stand angling hole
4. Insert the remote control sensor box connection cable
into the control kit terminal.
Connection cableControl kit terminal
Remote control
sensor box
TIPS
• Whenyouconnecttheremotecontrolsensorbox,the
brightness sensor can be used.
 Thescreenbrightnesswillautomaticallychangeaccording
to lighting conditions and the surrounding brightness. (See
OperationGuide.)
• Dependingonwhereithasbeenplacedorthesurrounding
conditions,theremotecontrolsensorboxmaybe
affected by the brightness of the main unit screen and the
brightness sensor may respond.
• Donotinstalltheremotecontrolsensorboxinextremely
brightordarkareas.Thebrightnesssensormaynot
function properly.
Brightness
sensor
Connecting Peripheral Equipment
