– 12 –
1. Lift the paper holder up. (Fig. 1)
2. Fold the leading edge of the paper roll 3 to 5 cm. (Do not fold it slantwise.) (Fig. 2)
3. Insert the paper roll from the left side of the paper holder and make sure the paper
roll is set in the proper direction (with the paper feeding from the bottom). (Fig. 3)
4. Insert the leading edge of the paper into the opening directly behind the print
mechanism. (Fig. 4)
5. Press the paper feed key and feed the paper under the edge of the paper cutter.
(Fig. 5)
PAPER ROLL REPLACEMENT
DO NOT PULL THE PAPER BACKWARDS AS THIS MAY DAMAGE THE PRINTER
MECHANISM.
Fig. 1 Fig. 2
Paper holder
Fig. 4
Fig. 3
Fig. 5
Paper cutter
