Sharp R-201EW - Parts List

30
R-201EW
∆
∆
*
*
*
*
*
∆
*
∆
*
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA137WRE0 Secondary interlock switch & door sensing switch 2 AH
1- 2 FFS-BA029WRK0
C/T fuse (13A, 120˚C) & monitor switch (AM51620C53Y1) assembly 1AS
1- 3 FACCDA079WRE0 Power supply cord 1 AF
1- 4 RTRN-A560WRE0 Power transformer 1 BK
1- 5 FH-DZA081WRK0 High voltage rectifier 1 AQ
1- 5 FH-DZA082WRK0 High voltage rectifier (Interchangeable) 1 AQ
1- 6 RC-QZA209WRE0 High voltage capacitor 1 AT
1- 6 RC-QZA199WRE0 High voltage capacitor (Interchangeable) 1 AW
1- 7 RMOTEA355WRE0 Fan motor 1 AU
1- 7 RMOTEA383WRE0 Fan motor (Interchangeable) 1 AV
1- 8 RV-MZA282WRE0 Magnetron 1 BP
1- 8 RV-MZA226WRE0 Magnetron (Interchangeable) 1 BE
1- 9 RLMTTA082WRZZ Oven lamp 1 AL
1-10 RMOTDA186WRE0 Turntable motor 1 AW
1-10 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-11 RTHM-A116WRE0 Thermal cut-out 125˚C 1 AK
CABINET PARTS
2- 1 GCABUA696WRP0 Outer case cabinet 1 AF
2- 2 GDAI-A304WRW0 Bottom plate 1 AF
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 DPWBFB972WRU0 Control unit 1 BA
3- 2 FPNLCB555WRKZ Control panel frame with key unit and LCD 1 BD
3- 2-1 FUNTKB046WREZ Key unit 1 AU
3- 2-2 RLCDSA089DRZZ Liquid crystal display 1 AM
3- 3 QCNC-A013WRZZ Rubber connector 1 AE
3- 4 XEPSD30P08XS0 Screw; Control unit mtg. 3 AA
OVEN PARTS
4- 1 PHOK-A105WRF0 Latch hook 1 AL
4- 2 LANGQA530WRWZ Light mount plate 1 AP
4- 3 PCUSUA502WRP0 Waterproof cushion 1 AD
4- 4 LBNDKA038WRP0 Capacitor holder 1 AF
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A694WRF0 Fan duct 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1--
4- 8 GLEGPA073WRF0 Leg 1 AD
4- 9 LANGTA318WRP0 Chassis support 1 AE
4-10 PCUSGA389WRP0 Cushion 1 AG
4-11 PCOVPA276WRE0 Waveguide cover 1 AM
4-12 PCOVPA342WRF0 B-cover Right 1 AH
4-13 PCOVPA343WRF0 B-cover Left 1 AH
4-14 PCUSUA443WRP0 Cushion 2 AE
4-15 PDUC-A700WRF0 Air separator 1 AN
4-16 PPACGA097WRE0 O-ring 1 AG
4-17 PCUSUA474WRP0 Cushion 1 AC
DOOR PARTS
5- 1 FDORFA321WRT0 Door panel 1 AT
5- 2 GWAKPA628WRF0 Door frame 1 AY
5- 3 HPNL-A738WRRZ Door screen 1 AS
5- 4 LSTPPA175WRF0 Latch head 1 AE
5- 5 MSPRTA084WRE0 Latch spring 1 AB
5- 6 PSHEPA622WRE0 Sealer film 1 AG
5- 7 GCOVHA390WRF0 Choke cover 1 AK
5- 8 XEPSD40P08000 Screw : 4mm x 8mm 4 AA
MISCELLANEOUS
6- 1 FROLPA089WRK0 Turntable support 1 AP
6- 2 NTNT-A060WRE0 Turntable 1 AP
6- 3 TINSEA885WRRZ Instruction book 1 AL
6- 4 FW-VZB657WRE0 Switch harness 1 AH
6- 5 FW-VZB831WREZ Main wire harness 1 AQ
6- 6 QW-QZA242WRZZ High voltage wire B 1 AF
