Sharp R-203CW User Manual

31
R-203CW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
3- 2-1 FUNTKA928WRE0 Key unit 1 AY
3- 2-2 RLCDSA045DRE0 Liquid crystal display 1 AM
3- 3 QCNC-A012WRE0 Rubber connector 1 AF
3- 4 XEPSD30P08XS0 Screw; Control unit mtg. 4 AA
OVEN PARTS
4- 1 PHOK-A105WRF0 Latch hook 1 AL
4- 2 LANGQA477WRW0 Light mount plate 1 AY
4- 3 PCUSUA502WRP0 Waterproof cushion 1 AD
4- 4 LBNDKA038WRP0 Capacitor holder 1 AF
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A694WRF0 Fan duct 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1--
4- 8 GLEGPA073WRF0 Leg 1 AD
4- 9 LANGTA318WRP0 Chassis support 1 AE
4-10 PCUSGA389WRP0 Cushion 1 AG
4-11 PCOVPA276WRE0 Waveguide cover 1 AM
4-12 PCOVPA342WRF0 B-cover Right 1 AH
4-13 PCOVPA343WRF0 B-cover Left 1 AH
4-14 PCUSUA443WRP0 Cushion 1 AE
4-15 PDUC-A700WRF0 Air separator 1 AN
4-16 PPACGA097WRE0 O-ring 1 AG
4-17 PCUSUA270WRP0 Cushion 1 AG
DOOR PARTS
5- 1 FDORFA321WRT0 Door panel 1 AT
5- 2 GWAKPA628WRF0 Door frame 1 AY
5- 3 HPNL-A686WRR0 Door screen 1 AY
5- 4 LSTPPA175WRF0 Latch head 1 AE
5- 5 MSPRTA084WRE0 Latch spring 1 AB
5- 6 PSHEPA622WRE0 Sealer film 1 AG
5- 7 GCOVHA390WRF0 Choke cover 1 AK
5- 8 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
MISCELLANEOUS
6- 1 FROLPA089WRK0 Turntable support 1 AP
6- 2 NTNT-A094WRE0 Turntable 1 AN
6- 3 TINSEA794WRR0 Instruction book 1 AD
6- 4 FW-VZB657WRE0 Switch harness 1 AH
6- 5 FW-VZB658WRE0 Main wire harness 1 AV
6- 6 QW-QZA150WRE0 High voltage wire B 1 AF
6- 7 TCAUAA166WRR0 DHHS caution label 1 AC
6- 8 TCAUAA156WRR0 User caution label 1 AF
6- 9 TCAUAA239WRR0 Monitor caution 1 AC
6-10 TCAUAA145WRR0 Earth caution 2 AG
6-11 TCAUAA240WRR0 Screw caution 1 AC
SCREWS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 5 AA
7- 2 LX-EZA042WRE0 Special screw 2 AB
7- 3 LX-WZA028WRE0 Special washer 1 AB
7- 4 LX-BZA125WRE0 Special screw 2 AA
7- 5 XHTSD40P08RV0 Screw : 4mm x 8mm 5 AA
7- 6 XHPSD30P08000 Screw : 3mm x 8mm 1 AA
7- 7 LX-CZ0052WRE0 Special screw 2 AA
7- 8 XOTSD40P12000 Screw : 4mm x 12mm 6 AA
7- 9 XOTSE40P08000 Screw : 4mm x 8mm 4 AA
7-10 LX-CZA071WRE0 Special screw (Torx tamper proof screw) 2 AC
7-11 LX-CZA073WRE0 Special screw 2 AC
7-12 LX-CZA076WRE0 Special screw 1 AC
∆
∆
∆
∆
*
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
