Sharp R-203CW - Parts List; Electric Parts; Cabinet Parts; Control Panel Parts

30
R-203CW
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA131WRE0 Secondary interlock switch & door sensing switch 2 AG
1- 2 FFS-BA020WRK0 C/T fuse & monitor switch assembly 1 AP
1- 3 FACCDA079WRE0 Power supply cord 1 AF
1- 4 QSOCLA021WRE0 Oven lamp socket 1 AH
1- 5 FH-DZA081WRK0 High voltage rectifier 1 AQ
1- 6 RC-QZA200WRE0 High voltage capacitor 1 AV
1- 6 RC-QZA201WRE0 High voltage capacitor (Interchangeable) 1 AW
1- 7 RMOTEA338WRE0 Fan motor 1 AV
1- 7 RMOTEA355WRE0 Fan motor (Interchangeable) 1 AU
1- 8 RV-MZA226WRE0 Magnetron 1 BE
1- 8 RV-MZA282WRE0 Magnetron (Interchangeable) 1 BP
1- 9 RLMPTA030WRE0 Oven lamp 1 AF
1-10 RMOTDA211WRE0 Turntable motor 1 AS
1-10 RMOTDA186WRE0 Turntable motor (Interchangeable) 1 AW
1-11 RTHM-A078WRE0 Thermal cut-out 125˚C 1 AK
1-12 RTRN-A561WRE0 Power transformer 1 BM
CABINET PARTS
2- 1 GCABUA696WRP0 Outer case cabinet 1 AF
2- 2 FDAI-A203WRY0 Bottom plate 1 BB
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 CPWBFA773WRK0 Control unit 1 BL
3- 1A QCNCMA431DRE0 2-pin connector (A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (B) 1 AB
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31EW477M Capacitor 470 uF 25V 1 AC
C3 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C4 VCEAB31CW476M Capacitor 47 uF 16V 1 AA
C5 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C6 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C21 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
C40 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C61-64 VCKYD11HB331K Capacitor 330 pF 50V 4 AA
C70 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C71 VCCCF61HH330J Capacitor 33 pF 50V 1 AB
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D20-22 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D40 VHD1SS270A/-1 Diode (1SS270A) 1 AA
IC1 RH-IZA868DRE0 LSI 1 AN
Q1 VS2SA933S//-3 Transistor (2SA933) 1 AB
Q20 VSKRA101M//-3 Transistor (KRA101M) 1 AB
Q21 VSKRC243M//-3 Transistor (KRC243M) 1 AB
Q22 VSDTA143ES/1B Transistor (DTA143ES) 1 AA
Q30 VSKRA101M//-3 Transistor (KRA101M) 1 AB
R1 VRD-B12HF911J Resistor 910 ohm 1/2W 1 AA
R2 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
R3-5 VRD-B12EF153J Resistor 15k ohm 1/4W 3 AA
R20 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R30 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R40 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R41 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R50-55 VRD-B12EF153J Resistor 15k ohm 1/4W 6 AA
R57-60 VRD-B12EF153J Resistor 15k ohm 1/4W 4 AA
R61-64 VRD-B12EF224J Resistor 220k ohm 1/4W 4 AA
R70 VRN-B12EK103F Resistor 10k ohm 1/4W 1 AA
R80 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
(J6) VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
(J7) VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
RY1 RRLY-A111DRE0 Relay (JV12S-KT) 1 AL
RY2 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
SP30 RALM-A014DRE0 Buzzer (PKM22EPT-CA) 1 AG
T1 RTRNPA110DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ4C3///-1 Zener diode (HZ4C-3) 1 AA
3- 2 FPNLCB426WRK0 Control panel frame with key unit and LCD 1 BE
*
*
*
*
∆
*
∆
*
