R21LTF
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
1-1
FFS-BA033WRKZ
-- Monitor fuse20A and monitor switch (V-5220Q)
1-2
QSW-MA085WRE0
AF Door sensing switch
1-3
QSW-MA135WRE0
AH Secondary interlock switch
1-4
FACCDA116WREZ
AV Power supply cord
!
1-5
FH-DZA119WRKZ
AU High voltage rectifier assembly
!
1-6
RC-QZA235WRE0
AU High voltage capacitor
!
1-6
RC-QZA336WRZZ
-- High voltage capacitor for production use (Interchangeable)
1-7
RMOTEA376WRE0
AU Fan motor
1-8
FPWBFA389WRKZ
AW Noise filter
1-8
FPWBFA417WRKZ
AY Noise filter (Interchangeable)
1-9
QSOCLA021WRE0
AG Oven lamp socket
1-10
RLMPTA086WRZZ
AL Oven lamp
1-11
RMOTDA233WRE0
AQ Antenna motor
1-12
RTHM-A138WRZZ
AH Thermal cut-out 145 deg. (MAG)
1-12
RTHM-A080WRE0
AP Thermal cut-out 145 deg. (MAG) (Interchangeable)
1-12
RTHM-A120WRE0
AH Thermal cut-out 145 deg. (MAG) (Interchangeable)
1-13
RTHM-A137WRZZ
AH Thermal cut-out 125 deg. (OVEN)
1-13
RTHM-A096WRE0
AK Thermal cut-out 125 deg. (OVEN) (Interchangeable)
1-13
RTHM-A123WRZZ
AK Thermal cut-out 123 deg. (OVEN) (Interchangeable)
!
1-14
RTRN-A751WRZZ
BP Power transformer
!
*
1-15
RV-MZA347WRZZ
BH Magnetron
CABINET PARTS
2-1
GCABUA672WRP0
BH Outer case cabinet
2-2
GDAI-A311WRW0
AS Base plate
2-3
GCOVHA406WRW0
AQ Base plate cover
2-4
GLEGPA074WRE0
AC Foot
2-5
GLEGPA076WRF0
AF Leg
OVENPARTS
4-1
FGLSPA062WRE0
BL Ceramic shelf
* 4-2
*************
-- Oven cavity (Not a replaceable part)
4-3
MLEVPA227WRF0
AF Latch switch lever A
4-4
MLEVPA228WRF0
AF Latch switch lever B
4-5
MLEVPA229WRF0
AF Latch switch lever C
4-6
MSPRCA108WRE0
AC Latch lever spring
4-7
MSPRTA191WRE0
AC Switch lever B spring
* 4-8
PHOK-A160WRFZ
AN Latch hook
4-9
FDUC-A341WRY0
BL Steam duct sub assembly
4-10
PSKR-A351WRP0
AY Steam guide
4-11
LBNDKA136WRP0
AQ HV capacitor holder
4-12
NFANJA029WRE0
AK Fan blade
4-13
PDUC-A888WRFZ
AM Fan duct
4-14
FPLT-A007WRY0
BB Stirrer antenna assembly
4-15
PCUSGA504WRP0
AB Insertion cushion
4-16
PSKR-A348WRW0
AN Insertion plate A
4-17
GCOVHA509WREZ
AG VCP cap
4-18
LANGFA199WRWZ
AH Chassis support
4-19
NSFTPA035WRFZ
AQ Antenna motor shaft
4-20
PCLICA032WRE0
AD Hand clip 4
4-21
PCLICA033WRE0
AD Hand clip 5
4-22
PCOVPA344WRF0
AF Side splash cover
4-23
PCOVPA345WRF0
AF Back splash cover
4-24
PCUSGA249WRP0
AA Cushion
4-25
PCUSUA511WRP0
AC Cushion
4-26
PCUSUA194WRP0
AC Cushion
4-27
PCUSUA514WRP0
AB Cushion
4-28
PDUC-A966WRFZ
AT Air intake duct
4-29
PFILWA060WRP0
AD Lamp filter
4-30
PSHEPA644WRE0
AD Insertion sheet
4-31
PSKR-A347WRW0
AL Insertion plate B
4-32
PSKR-A349WRP0
AF Steam duct barrier
4-33
PSKR-A359WRW0
AM Air guide
4-34
PSPA-A112WRE0
AC Mica washer
4-35
PCUSGA378WRP0
AL Cushion
4-36
PCUSUA507WRP0
AC Cushion
4-37
PCUSUA517WRP0
AE Cushion
4-38
PSHEPA674WRE0
AL Cover
4-39
PCUSUA518WRP0
AC Cushion
4-40
PSHEPA673WRE0
AD S/Film
MISCELLANEOUS
6-1
TMAPCA780WRRZ
AH Schematic diagram
6-2
TCAUAA249WRR0
AE Caution label
6-3
TCAUAA250WRR0
AF DHHS caution label
6-4
TCAUAA295WRRZ
AH Monitor caution
6-5
TCAUAA243WRR0
AC Earth caution
