R21LTF
4 – 1
R21LTF
Service Manual
CHAPTER 4. PRODUCT DESCRIPTION
[1] SPECIFICATIONS
ITEM DESCRIPTION
Power Requirements
120 Volts
14 Amperes
60 Hertz
Single phase, 3 wire grounded
Power Output
1000 watts (IEC Test procedure)
Operating frequency 2450 MHz
Outer Case Dimensions
Width 20-1/2" (520mm)
Height 12-1/8" (309mm)
Depth 16" (406mm)
Cooking Cavity Dimensions
Width 13-7/8" (353mm) NOTE: Internal capacity is calculated by measuring
Height 8-1/ 8" (207mm) maximum width, depth and height.
Depth 14-5/8" (370mm) Actual capacity for holding food is less.
Control Complement
Touch Control System
Timer (0 - 99 minutes 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI --------------------- Full power throughout the cooking time
P-90 -------------------- approx. 90% of FULL Power
P-80 -------------------- approx. 80% of FULL Power
P-70 -------------------- approx. 70% of FULL Power
P-60 -------------------- approx. 60% of FULL Power
P-50 -------------------- approx. 50% of FULL Power
P-40 -------------------- approx. 30% of FULL Power
P-30 -------------------- approx. 40% of FULL Power
P-20 -------------------- approx. 20% of FULL Power
P-10 -------------------- approx. 10% of FULL Power
P-0 ---------------------- No power throughout the cooking time
DOUBLE QUANTITY pad
EXPRESS DEFROST pad
Ten number pads
SELECTATIME pad
STOP/CLEAR pad
SELECTAPOWER pad (R-21LTF only)
START pad
SET pad
CHECK pad
SIGNAL pad
Oven Cavity Light Yes
Safety Standard
UL Listed.
FCC Authorized
DHHS Rules, CFR, Title 21, Chapter 1, Subchapter J, NSF certified
