Sharp R-21LTF User Manual

R21LTF
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1
DPWB-A417DRKZ
BQ Control unit [R-21LTF]
3-1
DPWB-A418DRKZ
BQ Control unit [R-21LVF]
3-2
FPNLCB912WRKZ
BB Control panel frame with key unit [R-21LTF]
3-2
FPNLCB913WRKZ
BB Control panel frame with key unit [R-21LVF]
3-2-1
FUNTKB173WREZ
AU Key unit [R-21LTF]
3-2-1
FUNTKB174WREZ
AU Key unit [R-21LVF]
3-2-2
GCOVAA260WRP0
BA C/P case
3-2-3
GMADIA109WRF0
AE Display window
3-3
TCAUAA076WRR0
AB User caution label
3-4
XEPS730P08XS0
AA Screw; 3mm x 8mm
DOOR PARTS
* 5-1
CDORFB052WRKZ
BT Door assembly
* 5-1-1
FDORFA322WRT0
AZ Door panel assembly
5-1-2
PSHEPA649WRE0
AB Sealer film
* 5-1-3
FANGKA206WRY0
AW Latch angle assembly
* 5-1-4
FCOV-A012WRKZ
BQ Door case assembly
5-1-4-1
LSTPPA180WRF0
AK Glass stopper R
5-1-4-2
LSTPPA182WRF0
AN Glass stopper U
5-1-4-3
PGLSPA516WRE0
AU Front door glass
5-1-4-4
PSLDMA198WREZ
BB Sealer plate
5-1-4-5
XETS740P08000
AA Screw : 4mm x 8mm
5-1-5
GWAKPA580WRM0
AQ Door handle
5-1-6
JHNDMA040WRW0
AN Handle lever
* 5-1-7
LANGKA874WRW0
AR Latch lever
* 5-1-8
LSTPPA181WRF0
AL Latch head
5-1-9
MSPRTA190WRE0
AD Latch spring
5-1-10
PCUSUA506WRP0
AC Cushion
5-1-11
XEPS740P06000
AA Screw : 4mm x 6mm
5-1-12
PSHEPA686WRE0
AK Panel sheet
5-1-13
PSHEPA687WRE0
AK Panel sheet
5-1-14
PCUSGA514WRP0
AK Cushion
5-1-15
PCUSUA505WRP0
AC Cushion
5-1-16
XEBS738P08000
AB Screw : 3.8mm x 8mm
5-1-17
XEPS740P25K00
AC Screw : 4mm x 25mm
5-1-18
PCUSUA508WRP0
AC Cushion
* 5-2
GCOVHA407WRF0
AM Choke cover
5-3
HBDGCA124WREZ
AK Door badge [R-21LTF]
5-3
HBDGCA122WREZ
AK Door badge [R-21LTF]
* 5-4
PPACGA171WRE0
AK Cushion (ferrite)
MISCELLANEOUS
6-7
TINSEB126WRRZ
AM Instruction book
6-8
FW-VZC074WREZ
AX Main wire harness
6-9
LHLDWA013WRE0
AC Purse lock LL

Sharp R-21LTF Specifications

General

Brand	Sharp
Model	R-21LTF
Category	Microwave Oven
Language	English
