R-222T(W)
3
NO. PARTS CODE DESCRIPTION Q'TY
PRICE RANK
[1] OVEN PART
ELECTRIC PARTS
1-1 QSW-MA085WRE0 1st. latch/ 2nd. interlock relay control switches AF
1-1 QSW-MA137WRE0 1st. latch/ 2nd. interlock relay control switches (Interchangable) AH
1-1 QSW-MA147WRE0 1st. latch/ 2nd. interlock relay control switches (Interchangable) AG
1-2 QSW-MA086WRE0 Monitor switch AF
1-2 QSW-MA138WRE0 Monitor switch (Interchangable) AH
1-2 QSW-MA148WRE0 Monitor switch (Interchangable) AF
1-3 QACC-A177WRZZ Power supply cord AQ
1-4 FH-DZA129WRKZ High voltage rectifier assy AN
1-5 RC-QZA218WRE0 High voltage capacitor AW
1-5 RC-QZA333WRZZ High voltage capacitor (Interchangable) AS
1-6 RMOTEA405WRZZ Fan motor AX
1-6 RMOTEA450WRZZ Fan motor (Interchangable) AV
1-6 RMOTEA460WRZZ Fan motor (Interchangable) AX
1-6 RMOTEA463WRZZ Fan motor (Interchangable) AX
1-6 RMOTEA475WRZZ Fan motor (Interchangable) AX
*
1-7 RV-MZA351WRZZ Magnetron BM
*
1-7 RV-MZA341WRZZ Magnetron (Interchangable) BG
1-8 RLMPTA101WRZZ Oven lamp AM
1-8 RLMPTA088WRZZ Oven lamp (Interchangable) AN
1-8 RLMPTA083WRZZ Oven lamp (Interchangable) AM
1-9 RMOTDA302WRZZ Turntable motor AN
1-9 RMOTDA299WRZZ Turntable motor (Interchangable) BE
1-9 RMOTDA289WRZZ Turntable motor (Interchangable) AQ
1-9 RMOTDA253WRZZ Turntable motor (Interchangable) AV
1-9 RMOTDA173WRE0 Turntable motor (Interchangable) AX
1-10 QFS-TA014WRE0 Temperature fuse 150C (Oven) AG
1-11 RTRN-A755WRZZ Power trnasformer BH
1-11 RTRN-A805WRZZ Power trnasformer (Interchangable) BG
1-12 FPWBFA387WRKZ Noise filter AW
1-13 QFS-CA027WRZZ Fuse T6.3A AG
1-14 QFS-IA016WRZZ High voltage fuse 0.60A AN
1-14 QFS-IA004WRE0 High voltage fuse 0.60A (Interchangable) AK
CABINET PARTS
2-1 GCABUB220WRPZ Outer case cabinet BC
2-2 GDAI-A459WRWZ Bottom plate AF
2-3 GLEGPA104WREZ Foot AF
OVENPARTS
*
4-1 PHOK-A144WRFZ Latch hook AL
4-2 LBNDKA168WRPZ2 Capacitor holder AF
4-3 NFANJA053WRFZ Fan blade AG
4-4 PDUC-A908WRWZ2 Fan duct AG
4-5 FOVN-A634WRTZ Oven cavity BC
4-6 LANGFA267WRPZ2 Chassis support AF
4-7 MLEVPA241WRFZ Switch lever AG
4-8 PCOVPA419WREZ Waveguide cover AG
4-9 PDUC-A909WRPZ Air duct AN
4-10 PPACGA084WRF0 TTM packing AE
4-11 PCUSUA501WRP0 Cushion AB
4-12 PPACGA276WREZ Cushion AG
4-13 PCUSGA661WREZ Cushion AD
4-14 PCUSGA615WRPZ Cushion AE
4-15 PCUSUA278WRP0 Cushion AB
4-16 PSPAJA007WRFZ Spacer AF
4-17 PCUSUA647WRPZ Cushion AC
MISCELLANEOUS
6-1 NTNT-A034WRF0 Turntable AM
6-2 FROLPA113WRKZ Turntable support AS
6-6 TCAUHA343WRRZ Micro caution AF
SCREWS,NUTS AND WASHERS
7-1 XHPS740P08K00 screw : 4mm x 8mm AB
7-2 XHTS740P08RV0 Screw : 4mm x 8mm AG
7-3 XOTS740P12000 Screw : 4mm x 12mm AA
7-4 LX-CZ0052WRE0 Special screw AA
7-5 XOTS740P08000 Screw : 4mm x 8mm AA
7-6 LX-CZA073WRE0 Special screw AC
7-7 XHPS740P08000 Screw : 4mm x 8mm AA
7-8 XOTS740P08000 Screw : 4mm x 8mm AA
7-9 XOTS740P12RV0 Screw : 4mm x 12mm AD
7-10 XETS740P10000 Screw : 4mm x 10mm AA
